Polygroup TG76M4244L04 Assembly Instructions

TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from
Carefully follow the instructions below on how to quickly and easily set up your new tree.
Fig. A - Tree and Light Assembly
Quick Fold
Quick Fold TM
Quick Fold TM Cinch
1
• Before you start to assemble your tree, choose an appropriate location near a wall outlet.
• Do not plug the adaptor into the wall outlet while it in the packaging.
• Assemble the tree stand and place on a level surface. (See Fig. B)
Fig. B - Tree Stand Assembly
SET UP INSTRUCTIONS WITH QUICK FOLD
1
Section 2
Section 1
Tree top
Each tree section is numbered
with a tag. Please identify all
sections before assembling.
MODEL #: TG76M4244L04
Polygroup®!
3
TM Cinch
Cinch
2
2
Section 1
Insert Section 1 into the tree stand.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120VAC, 60Hz, 0.25A Max.
Output: 29V DC 0.45A
Do Not Tamper
Internal Parts
Quick Set®
Connections
Open the
protective
cover
Quick Set®
Connections
Insert Green
Label Extension
Cord into Adaptor
Unfold the legs and lay the
stand in a flat area. Then slide
the locking disc downward and
snap into place.
TM
3
A
Cinch
Handle
Cinch Clip B
C
A. Locate "Pull Here" tab and corresponding
Cinch Handle
B. Hold Cinch Clip firmly with one hand and
press down on clip
C. With Cinch Clip depressed, pull clip away from
tree until all branches are released.
1
Do Not Tamper
Internal Parts
Open the
protective
cover
Adaptor
To Be Plugged
Into Wall
Outlet
