Prestige
Venturi Replacement
Kit Part Number
Each Kit Includes:
• Venturi
• Venturi/Blower Gasket
• Venturi Screws
WARNING
!
Indicates a potentially hazardous situation which,
if ignored, can result in serious injury or substan-
tial property damage.
WARNING
!
For your safety, turn off electrical power supply
at service panel and allow unit to cool before pro-
ceeding to avoid possible electrical shock and
scald hazard. Failure to do so can cause severe
personal injury or death.
2020-19 Prestige CTRLMax Venturi Replacement
Revised 1/10/2020
Description
PSRKIT83
Venturi Replacement
TCRKIT19
Venturi Replacement
Model
Prestige 250
Prestige 299/399
Recommended Tools:
• Adjustable Wrench
• Torx Screwdriver
• Phillips Head Screwdriver
NOTICE
Indicates special instructions on installation, operation
or maintenance, which are important to equipment
but not related to personal injury hazards.
WARNING
!
Failure to follow instructions below can result in
severe personal injury or damage if ignored.
•
Instructions are for a qualified installer/ ser-
vice technician only.
•
Read all instructions before proceeding.
•
Follow instructions in proper order.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TriangleTube PSRKIT83
Summary of Contents for TriangleTube PSRKIT83
- Page 1 Prestige Venturi Replacement Kit Part Number Description Model PSRKIT83 Venturi Replacement Prestige 250 TCRKIT19 Venturi Replacement Prestige 299/399 Each Kit Includes: Recommended Tools: • Venturi • Adjustable Wrench • Venturi/Blower Gasket • Torx Screwdriver • Venturi Screws • Phillips Head Screwdriver...
- Page 2 Prestige Venturi Replacement 1. Preliminary Instructions: 1. Verify that the Venturi replacement kit is correct for the model of boiler. See table on page 1. 2. Carefully open and unpack the PARTS BOX from its shipping carton. 3. Carefully remove and check for any damage. NOTICE Do not proceed with installation and contact Triangle Tube right away if the venturi is damaged in any way.
- Page 3 Prestige Venturi Replacement Table 1: Recommended Combustion Settings WARNING Nat. Gas Propane Propane Ensure the o-ring/gasket are in place before reassem- All Modes 250/299 bly. Failure to do so can result in death, serious injury Range 8.8 to 10.7 to 10.4 to or substantial property damage.
- Page 4 Prestige Venturi Replacement 1. Press the round INSTALLER button. 6. If the combustion levels during high fire are outside the recommended combustion settings adjust the Installer Button THROTTLE SCREW using a flat-blade screwdriver as follows: Counter-clockwise adjustment of the THROTTLE SCREW at High Fire (100% firing rate): O2 decreases and CO2 increases Target = 186°F...
