GB
Removal
Any service work involving electrical components should only be car-
ried out by a recognised service engineer. In any case please call the
service hotline.
Removing the bowl:
· Shut off water supply and disconnect.
· Unscrew the bracket screws on the back of the toilet.
· Release the discharge pipe from discharge elbow (I)
· Incline the toilet frontwards and drain residual water into a bucket in
order to empty the toilet.
Removing the motor
· Remove the side screws which hold the motor case
· Remove the clear hose from the pneumatic push button (11)
· Remove the water supply hose (6)
· Unscrew the gear clamp (20) between the elbow and the case of the
motor.
· Remove the motor from the bottom of the toilet.
Opening the motor
· Remove the screws to release the lid on the motor case (30)
· Check out that the shaft is rotating properly
Warning: the knives are very sharp
· Proceed with cleaning if needed
· Grease the cover gasket before reinstalling.
Warranty
Your waterGenie Compact has a two year warranty from its day of
purchase, subject to correct installation and usage.
SETMA (Deutschland) GmbH
Siemensstrasse 3
D-85716 Unterschleissheim
Tel. +49 (0)89 / 317 13 19
Fax +49 (0)89 /317 57 66
