GB
Commissioning of the unit
Connect the toilet to the electrical supply. Open the water
supply completely in order to have an efficient rising
stage. To activate the flushing cycle, push the button
mounted on the rear edge of the pan. Throw a few toilet
paper sheets in the bowl and start the cycle again.
Attention: The basin tap should be watertight. Any drip-
ping will cause the motor to activate in regular short
bursts.
Use
waterGenie Compact can be used like a "normal" WC
and does not require any special maintenance.
Warning: as a normal WC, waterGenie Compact should
only be used for the evacuating of normal human waste,
toilet paper and household WC cleansers. Damage may
occur to the machine if the following are disposed of via
the WC; cotton wool, tampons, sanitary towels, wet wipes,
kitchen towels, condoms as well as other fabric or hard
objects. Solvents, acids and other chemicals can also
cause damage to the unit, and will invalidate the warranty.
Warning: In case of a long electrical shut off (vacation,
strike, work being done on the electrical or water supply)
close the water supply.
Cleaning
To clean the bowl use regular bathroom cleaning products.
To avoid accumultions of scale inside the motor, we advise
you to clean it regularly. To do so:
· Shut off water supply
· Flush the toilet
· Pour one liter of bathroom cleaning product
or (vinegar) in the bowl.
· Leave sit for a few hours
· Open water supply and flush the toilet
several times.
The frequency of cleaning depends on the hardness of the
water in your area. We advise you to do it at least once a
year. Do not put acids, caustic sodas or solvents down
waterGenie Compact.
For a long life of your unit...
· Regular cleaning
· Please use only normal toilet paper. Humidified paper might block the mace-
rating unit.
· The use of a filter between shut off valve and the toilet is not useless.
· In case of longer absence (holidays) close the water supply
· First vertical and the horizontal discharge. Otherwise (or diagonal) evacua-
tion may damage the motor unit.
Fault finding / Remedies
For the most part any inconsistencies in the operation of the unit will be minor
and easily rectified. Please refer to the chart below. If the problem cannot be
easily remedied in this way, please call our service organisation.
Warning: Always disconnect the electricity supply before attempting any work
on the unit !!!
Symptom Possible Cause
·The one way valve
The flushing cycle
(48) is not operating
activates normally, the
normally
motor turns, but the
water leaves the pan
slowly or not at all · The discharge pipe is
blocked
· The grille (62) is bloc-
ked
The motor activates A foreign object has
with a mechanical /
entered the blade / grille
rattling sound area (65/62)
The cycle starts, but · water inlet filter on
water enters into the electrovalve (28) bloc-
ked.
pan too slowly or not
at all. · The electrovalve is
defective.
Remedy
· Clean or replace valve
· Remove and clean
· Remove and clean
Remove the motor block,
take out the foreign object
through the opening in
motor cover (22). If
unsuccessful, dismantle.
· Remove and clean the
filter
· Replace the electrovalve
SETMA (Deutschland) GmbH
Siemensstrasse 3
D-85716 Unterschleissheim
Tel. +49 (0)89 / 317 13 19
Fax +49 (0)89 /317 57 66
