TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from Polygroup®! This tree comes with Quick Set® and Simple Shape
and light up your tree in less than 10 minutes! Carefully follow the instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Eye Bolt
Fig. B - Tree and Light Assembly
Section 1
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from bottom to tree top. Start with the section 1 and remove protective cap before inserting into the
assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Insert the remote controller into the wall outlet.(see Fig. B), your entire tree should now be lit. If some bulbs do not light or
flickers, search for any loose plugs and/or broken, loose or missing bulbs. Connecting the plugs or replace the bad bulbs
promptly in order to maintain the performance and life expectancy of your pre-lit tree.
7. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch
hinges. * The lights will remain lit even if one bulb burns out.
MODEL #: TGC0P4693L03
1-888-919-0070
OR
Eye Bolt
Click
Tree top
Section 4
Section 3
Section 2
1. Pull apart the legs of the stand so that they are
snapped into an x-shape, place the tree stand
on a level surface.
2. When inserting the bottom section of the tree
into the assembled stand, insert and turn the
eyebolts into the stand and tighten until the
tree pole is firmly secured.
To close the stand, remove the eyebolts, press
the metal button and fold the legs together.
Do Not Tamper
Internal Parts
Open the
protective
cap
Do Not Tamper
Internal Parts
Open the
protective
cap
Plug Adapter
Into Wall
Outlet
Fig.F
Timer
Foot Pedal
Insert the adapter into the timer, insert the timer
on/off Switch
into the extension cord, and insert the extension
cord plug into remote controller. Then insert the
remote controller into the wall outlet.
1
TM
technology-Set up
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120V, 60Hz, 0.35A
Output: 29V DC 0.69A
Remote Controller
On
Off
Extension Cord
