TREE ASSEMBLY INSTRUCTIONS

Congratulations on purchasing your new tree from
Quick Set® technology-Set up and light up your tree in less than 10 minutes! Carefully
follow the instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Eye Bolt
Fig. B - Tree and Light Assembly
Section 2
Section 1
3. Each tree section is numbered with a tag. Please identify all sections before assembling.
4. Assemble the tree from bottom to tree top. Start with the bottom section and remove the protective
cap before inserting into the assembled stand. Make sure the pole is firmly inserted and secured into
the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all
wires are free of branch hinges.
7. Insert green label plug into the wall outlet.(see Fig. B ), your entire tree should now be lit. If some bulbs
do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Connecting the
plugs or replace the bad bulbs promptly in order to maintain the performance and life expectancy of
your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from
the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
MODEL #: TGC0P3499C06
Polygroup®!
Eye Bolt
Click
Section 5
Section 4
Section 3
Side view
This tree comes with
1. Pull apart the legs of the stand so that
they are snapped into an x-shape, place the
tree stand on a level surface.
2. When inserting the bottom section of the tree
into the assembled stand, insert and turn the
eyebolts into the stand and tighten until the
tree pole is firmly secured.
To close the stand, remove the eyebolts, press
the metal button and fold the legs together.
*Electrical Rating For The Tree
(For Indoor Use Only)
3.74A 120V 60Hz
Do Not Tamper
Internal Parts
Open the
protective
cover
Insert
Green Label
Plug Into Wall
Outlet
Please scan code to
learn how to shape
and set up your tree
Do Not Tamper
Internal Parts
Open the
protective
cover
