ENGLISH
Important safety instructions! Please read before connection!
DANGER! (Electrical shock due to high voltages in the device)
The housing must not be removed! There are no parts to be maintained in the device.
Inside the unit there are components which are under high electrical voltage.
Before each use, check the device for damage or the absence of components, protective
devices or housing parts. If this is the case, the device must not be used!
Leave maintenance and repair work to a qualified service workshop or contact your
dealer. In the case of a malfunction of the device, operation must also be stopped
immediately until the device has been repaired by a specialist!
DANGER! (Electric shock due to short circuit)
Modifications to the power cord or plug are prohibited. If the power cord is damaged, it
must be replaced immediately with an original spare part from the manufacturer. Failure to
do so may result in fire or death due to electric shock!
DANGER! (For babies and children)
Dispose of or store any packaging material properly! Packaging material must be kept out
of the reach of babies and children due to the risk of suffocation.
Ensure that children never use the appliance unattended! In addition, make sure that
children do not remove (small) parts from the device, as they could suffocate by swallowing
parts!
WARNING! (High light intensity - eye injuries)
A direct view into the light source is absolutely to be omitted!
WARNING! (Epilepsy)
Stroboscopic effects (flashes of light) can trigger seizures of epilepsy in some people.
Accordingly sensitive people should be warned and should not be in the vicinity of such
devices.
Hint! (Fire hazard due to overheating)
The maximum permissible ambient temperature of this device is 40°C.
Ensure that the unit is placed in a well-ventilated location away from direct heat sources,
naked flames, combustible materials, and liquids. A minimum distance of 1 m is required.
Do not tape or cover the ventilation slots of the unit.
Advertisement
Table of Contents
Related Manuals for Lightmaxx VEGA ARC Pro I
Summary of Contents for Lightmaxx VEGA ARC Pro I
- Page 1 ENGLISH Important safety instructions! Please read before connection! DANGER! (Electrical shock due to high voltages in the device) The housing must not be removed! There are no parts to be maintained in the device. Inside the unit there are components which are under high electrical voltage. Before each use, check the device for damage or the absence of components, protective devices or housing parts.
- Page 2 ENGLISH Hint! (Operating conditions) In accordance with DIN EN 60529, the protection class designation IP (International Protection) is appended to 2 code numbers. The 1st code number stands for the extent of protection of a housing against foreign bodies and contact. The 2nd code number, on the other hand, describes the scope of protection against the ingress of water.
-
Page 3: Installation
ENGLISH Symbols on device and packaging: The lightning flash symbol warns the user of uninsulated voltages and the risk of electric shock. The exclamation mark symbol draws the user’s attention to important maintains and operating instructions in the manual. This symbol defines the minimum distance of the object to be illuminated. Read the manual Please read and follow the warnings and recommendations carefully to ensure safe and trouble-free use. -
Page 4: Intended Use
Manual Intended use: The lightmaXX VEGA ARC Pro I was designed for use as an electronic LED lighting effect. The device may only be used for this purpose and in accordance with the operating instructions. Other purposes as well as operation under other operating conditions are expressly not intended and can lead to damage to property or personal injury! No liability is assumed for damage resulting from improper use. -
Page 5: Operating Mode Dmx
ENGLISH Set up: All connections of the device should be made before switching on. Only use high-quality cables that are as short as possible for the connections. Configuration of the DMX connector: Resistance 120 ohm // ¼ w between pin 2 (DMX-) and pin 3 (DMX+) oft he last fixture. Operating mode DMX: Connect the DMX input of your device to the DMX output of your DMX controller, your DMX software or the DMX output of a device already in your DMX line. - Page 6 ENGLISH 8 Channel Mode: Channel Value Function Master Dimmer 000-255 (0 - 100%) Red Dimmer 000-255 (0 - 100%) Green Dimmer 000-255 (0 - 100%) Blue Dimmer 000-255 (0 - 100%) White Dimmer 000-255 (0 - 100%) Strobe Effect 000-255 (Speed: slow to fast) Macrofunction 000-255...
-
Page 7: Operation
ENGLISH Static, Auto or Sound mode: The device contains automatic programs that run according to fixed schemes (Auto) or are recalled via the built-in microphone to match the music (Sound). The selection of the respective mode takes place via the menu directly on the device. If you connect several devices of the same type via DMX, they can be controlled simultaneously via the master device. -
Page 8: Connections And Controls
ENGLISH Connections and controls: Bezeichnung Bezeichnung Locking Screw Operating keys Mounting Bracket DMX Input (3-pole) LED Lense DMX Output (3-pole) Cooling fin Power Supply (PowerCon) Display Power Output (PowerCon) - Page 9 ENGLISH Menu: Navigation in the menu is via the four menu buttons below the display. Use the "Mode" button to activate the menu, navigate via the "Up" and "Down" buttons. A corresponding selection is confirmed with the "Enter" key. The menu structure in detail:...
-
Page 10: Specifications
ENGLISH Specifications: Model VEGA ARC Pro I Power supply AC110-240V,50/60HZ Power consumption 120 Watt LEDs 18 x 5 Watt RGBW Color Mixing (Red – Green – Blue – White) Beam angle 45° Protection Class IP65 Operating Modes Auto, Sound Mode, Master/Slave, DMX... -
Page 11: Troubleshooting
ENGLISH Troubleshooting: The following overview serves as an aid for quick troubleshooting. If you are unsure, contact the manufacturer, the dealer or the corresponding specialist personnel. Never open the device on your own! Symptom Troubleshooting No function Check the mains connection and the fuse Check the cable connections No reaction in DMX mode Check your DMX address setting... -
Page 12: Environmental Protection
ENGLISH Environmental protection: The company MUSIC STORE professional GmbH always strives to reduce the burden of packaging to a minimum. The use of environmentally friendly and recyclable materials is of fundamental importance to us. Please dispose of and recycle the packaging components after use properly. Disposal of packaging: Ensure that paper packaging, plastic materials, etc. - Page 13 ENGLISH Notes MS ID: LIG0016702-000 02/2020...
