Delfield UC4472N-12 Specifications

UC4472N SALAD TOP
Reduced Height Front-Breathing Self-Contained Compact Salad Top
Refrigerators
MODELS:
❑ UC4472N-12 Two section with doors
Twelve pan capacity
❑ UC4472N-18 Two section with doors
Eighteen pan capacity
UC4472N-18
SPECIFICATIONS
Exterior top is one-piece 22-gauge stainless steel
with integral 2.12" (5.1cm) square nosing at the front.
Top has openings to accept 12 or 18 1/6-size 4"- 6"
(10.2cm - 15.2cm) deep plastic pans. Adapter bars and
1/6 pans are supplied by Delfield. Temperature in top
opening to maintain 33°F (1°C) to 41°F (5°C), with
pans recessed 2.5" (6.4cm) at 86°F ambient room
temperature, meeting NSF 7 requirements. One 72"
x 10" x .5" (183cm x 25.4cm x 1.3cm) polyethylene
cutting board treated with antimicrobial agent is
mounted on the top at the front edge.
Exterior back and bottom are two-piece 24-gauge
galvanized steel. Exterior ends are stainless steel.
Interior sides are thermoformed ABS plastic with shelf
supports. Base is fully insulated with high-density foamed
in place polyurethane.
❑ UCD4472N-12
❑ UCD4472N-18
STANDARD FEATURES
• Patented air screen ensures product stays cold without drying it out
• All 4400 Series units are 100% front breathing, which allows the
unit to be pushed against a wall or built into a cabinet or an existing
line up
• Durable, rugged stainless steel sides, top and front
• Features Delfield's exclusive ABS interior (on sides). ABS is
extremely durable - it won't dent, chip or corrode and is backed by
a limited lifetime warranty
• Delfield supplies 1/6 size pans and adapter bars for top opening
• Salad top refrigerators are standard with 10" wide, dishwasher safe
polyethylene cutting board treated with anitmicrobial agent
• "D" prefix models feature Delfield's new drawer system. Drawers
are backed by a 10-year warranty on the track assembly
• Environmentally friendly R404A refrigerant
• High density foamed in place polyurethane keeps energy costs low
• Black recessed quick grip handle
• Standard on 2" casters for easy cleaning and installation
• 7' cord and plug supplied
• Cord spring relief - prevents cord rollover
• One epoxy coated wire shelf standard, installed per door section
• ACT solid state electronic control
• One year parts and 90 day labor standard warranty.
Refrigeration system uses HFC-404A refrigerant.
Compressor is 1/2 H.P., with condenser coil and condensate
evaporator mounted on rear of the cabinet. Evaporator coils
are located on the interior rear wall of the cabinet. Refrigerant
flow is controlled by a capillary tube. Cabinet maintains an
interior cabinet temperature of 36°F to 40°F (2°C to 4°C).
ACT control. ACT electronic, solid state control, mounted
on the exterior rear of the cabinet, allows unit to maintain
precise temperatures in heavy duty conditions.
Electrical connections are 115 volt, 60 Hertz, single phase.
Unit has a 7' (2.1m) long electrical cord and NEMA 5-15P
plug.
Casters: Equipment is mounted on 2" (5.08cm) diameter
casters, with front three locking. Equipment clearance above
the floor is 2.5" (6.35cm).
980 S. Isabella Road Phone: 800-733-8948
Mt. Pleasant, MI 48858 Fax: 800-669-0619
www.delfield.com Email: info@delfield.com
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
Two section with drawers
Twelve pan capacity
Two section with drawers
Eighteen pan capacity
OPTIONS AND ACCESSORIES
Flat lift off cover
❑
18" wide single tier overshelf
❑
Stainless steel finish on back
❑
Plastic laminate on front
❑
❑ Additional wire shelves
Door lock
❑
Exterior thermometer
❑
Interior lights
❑
Glass door(s)
❑
❑ *220V/50 Hertz electrical system
*Inclusion of this option will alter electrical
specifications of the unit.
The following applies to three door models only
Doors have a 24-gauge stainless steel exterior, with
thermoformed ABS plastic interior liner. Cabinet has
one adjustable epoxy-coated wire shelf per door
opening.
The following applies to six drawer models only
Drawer fronts have a 24-gauge stainless steel exterior,
with thermoformed ABS plastic interior liner. Drawer
frames and slides are 12-gauge stainless steel. Drawer
slides are 11-gauge stainless steel with Delrin bearings.
Each section has two drawers. Each top drawer holds
one full size 12" x 20" (30.5cm x 50.8cm) pan and
three 1/9 size pans 4" - 6" (10.6cm -15.2cm) deep.
Each bottom drawer holds one 12" x 20" (30.5cm x
50.8cm) pan 4" (10.6cm) and three 1/9 size deep
pans. Pans supplied by others.
Approval _________________
Date____________________
