- Page 1 INSTRUCTION MANUAL Cordless Metal Shear DJS200 Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: DJS200 Max. cutting capacities * Steel up to 400 N/mm 2.0 mm (14 ga) Stainless Steel up to 600 N/mm 1.6 mm (16 ga) Strokes per minute 0 - 3,000 min Overall length 345 mm Rated voltage D.C. 18 V Net weight 2.2 - 2.5 kg... - Page 3 Avoid body contact with earthed or grounded Always wear protective goggles to protect surfaces, such as pipes, radiators, ranges and your eyes from injury when using power tools. refrigerators. There is an increased risk of elec- The goggles must comply with ANSI Z87.1 in the USA, EN 166 in Europe, or AS/NZS 1336 tric shock if your body is earthed or grounded.
- Page 4 When using the tool, do not wear cloth work Do not touch the blade or the workpiece imme- gloves which may be entangled. The entangle- diately after operation. They may be extremely ment of cloth work gloves in the moving parts may hot and cause burn your skin. result in personal injury. Avoid cutting electrical wires. It can cause serious accident by electric shock. Battery tool use and care 10.
-
Page 5: Functional Description
18. Keep the battery away from children. SAVE THESE INSTRUCTIONS. CAUTION: Only use genuine Makita batteries. Use of non-genuine Makita batteries, or batteries that have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and charger. Tips for maintaining maximum ► 1 . Red indicator 2. Button 3. Battery cartridge... -
Page 6: Overheat Protection
Overheat protection Indicating the remaining battery capacity When the tool or battery is overheated, the tool stops Only for battery cartridges with the indicator automatically and the lamp blinks. In this case, let the tool and battery cool before turning the tool on again. Overdischarge protection This protection works when the remaining battery capacity gets low. In this situation, remove the battery from the tool and charge the battery. Switch action CAUTION: Before installing the battery car- tridge into the tool, always check to see that the switch trigger actuates properly and returns to the "OFF"... - Page 7 Removing shear blades Lighting the lamp NOTICE: Hold the blades and the sleeve not to fall CAUTION: Do not look in the light or see the from the cutting head. source of light directly. NOTICE: Be careful not to lose the sleeve. To turn on the lamp, slightly pull the switch trigger, and Remove the bolts which hold the blades.
-
Page 8: Operation
Installing cutting head OPERATION CAUTION: Secure the cutting head firmly. Adjusting shear blade Otherwise the cutting head may rotate during opera- tion and cause serious injury. Adjust the side blade L to prevent the curl of the Insert the cutting head into the tool by turning it left and workpiece from contacting the cutting head and the right alternately. Then tighten the three bolts with the workpiece. hex wrench (5/32"). Loosen bolts with the hex wrench (5/32"). Move the side blade L back and forth to adjust it. Then tighten the three bolts with the hex wrench (5/32"). -
Page 9: Maintenance
Centers, always using Makita replacement parts. OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other ► 1 . Rotation button accessories or attachments might present a risk of injury to persons. Only use accessory or attachment Cutting operation for its stated purpose. - Page 12 Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885782A926 www.makita.com 20200525...
