Definitive Technology UIW RCS II Owner's Manual page 9

Reference series in-ceiling speaker

Hide thumbs Also See for UIW RCS II:

Diagram 1

EXISTING CEILING JOISTS

24" ON-CENTER

NOTE: UNIT DOES NOT NEED TO BE CENTERED

BETWEEN JOISTS. ALLOW FOR 1-1/4" OF CLEARANCE

ADDED FRAMING

ON EACH SIDE OF CLEAR LOCK ARMS

MATERIAL

14-1/2"

CAVITY SIZE REQUIRED

14-3/8"

BETWEEN INSTALLED

TEMPLATE

FRAMING MATERIAL

CUT-OUT

14-3/8" TEMPLATE CUT-OUT

LOCK ARM

(6 PLACES)

WOODSCREW

Diagram 2

(4 PLACES)
