Definitive Technology UIW RCS II Owner's Manual page 5

Installation Procedure Overview
• The speaker enclosure needs to be against joists or framing material on the
2 parallel sides that are to be fastened with the screws.
• The clearance required on outside ceiling surface is 1" around the cutout to
clear the speaker bezel. On inside surface, 1
clear lock arms on the sides that will not be fastened to the joists or framing
material.
• Also note that the installation of the RCS II may require some modification
of the joist structure in your ceiling. This should only be done by a compe-
tent professional who will configure the studs to maintain their structural
integrity and make sure that everything is in compliance with all local and
state building code requirements.
• Speaker wire must be run inside your ceiling as part of the installation
process of in-wall loudspeakers. Plan the connection before you start your
loudspeaker installation.
Step-by-Step Installation
Mounting options overview
• Installation of this product must follow all local and state building codes.
• We strongly recommend using a qualified, professional installer who is
knowledgeable of local building codes.
Required cutout and cavity size
• Template cutout size: 14
• Minimum size of installation cavity (inside ceiling and between joists)
is as follows:
– Depth: 5 7 / "
8
– 14 1 / " between joists on the sides the wood screws are to be installed in.
2
– 16 1 / " between joists on sides the lock arms are to be used
2
(1 1 / " of space required on each side to clear lock arms).
4
See Diagram 1, page 9 for reference.
3 / "W x 14 3 / "L.
8 8
(continued)
1 / " of clearance is required to
4
5
