- Page 1 Voyager III and Edge II Motherboard Replacement Field Service Bulletin 806660 – Revision 0 – July 2010...
-
Page 2: Materials And Tools
Engage the emergency Stop button on the CNC and disconnect electrical power before performing any maintenance. Introduction Purpose This FSB describes the steps for replacing the motherboard in the Voyager III and Edge II CNCs. Materials and tools No. 2 Phillips screwdriver Kit 228560 contents... -
Page 3: Remove The Motherboard
VOYAGER III AND EDGE II MOTHERBOARD REPLACEMENT Remove the motherboard Before you begin to remove the motherboard, take careful notes about the position and orientation of all cables as you disconnect them. 1. To open the front panel, remove the screws that secure the top and bottom of the panel. Open the panel. -
Page 4: Replace Cables
VOYAGER III AND EDGE II MOTHERBOARD REPLACEMENT Replace cables The cables that you connect to the new motherboard depend on the type of DC power cable that was used on the motherboard you removed. To discover which cables to use, look at the DC power cable connector on the old motherboard. If it has 24 pins, you can use all the original cables on the new motherboard. - Page 5 If the DC power cable connector on the old mother board has 20 pins, as shown below, you must use the DC power (CABL-0276 and PS_ON (CABL-0278) cables that are supplied in this kit. Refer to Voyager III installation or Edge II installation for details.
- Page 6 Voyager III installation If you are replacing the motherboard in a Voyager III CNC and the DC power cable connector on the old motherboard has 20 pins, use the following instructions to replace cables and DRAM module on the new motherboard. Refer to the wiring diagram for details about cable routing and connectors.
- Page 7 VOYAGER III AND EDGE II MOTHERBOARD REPLACEMENT Edge II installation If you are replacing the motherboard in an Edge II CNC and the DC power cable connector on the old motherboard has 20 pins, use the following instructions to replace cables and DRAM module on the new motherboard. Refer to the wiring diagram for details about cable routing and connectors.
- Page 8 Hypertherm and Voyager are trademarks of Hypertherm, Inc. and may be registered in the United States and/or other countries. Hypertherm and Voyager sont des marque de commerce d’Hypertherm, Inc. et peut être déposée aux États-Unis et/ou dans d’autres pays. Hypertherm, Inc.
