Step 8
Attaching the monitor to the plate
1
D
A or B
Use washer
if needed (D)
3
D
A
4pcs
D
8pcs Ø6.5*Ø13*2 washer
A or B
A or B
11 /15
B
M4*12mm screw
4pcs
G
1pc
2
M5*12mm screw
5x5 Allen key
G
5x5
Allen Wrench
