Summary of Contents for J.Burrows Elite MA300
- Page 1 Item No.: Elite MA300 GAS SPRING MONITOR ARM WITH USB HUB INSTRUCTION MANUAL 2.5-8.5kg 1 / 12...
- Page 2 3x3 allen key VESA plate Base 50cm Type-C cable Instruction manual 2 / 12...
- Page 3 Preparation before installing monitor 1. Make sure there are VESA holes 100x100mm or 75x75mm in the monitor. If not, the mount cannot be installed. 2. Remove the original fixed base of monitor. Be careful not to scratch the screen. 75x75 or 100x100 3 / 12...
- Page 4 Option 01: Clamp Caution Tabletops only. This clamp cannot be mounted on other tabletops without risk of the clamp or parts falling. 4 / 12...
- Page 5 Option 2: Grommet 5 / 12...
- Page 6 Connect the upper and lower arm support to the base Tightent it with a 3x3 allen key (11) after inserting 6 / 12...
- Page 7 Attaching the monitor to the plate monitor Use washers (D) if screw holes in monitor are not deep enough to ensure the monitor and VESA plate are tightly secured Tighten the screw with the cross end of the allen key (F) Tighten 7 / 12...
- Page 8 Install the monitor to the arm support Hang the monitor from top to bottom on the connection plate and make sure it is attached firmly. 8 / 12...
- Page 9 Adjust the monitor If the monitor cannot stop at any height, please monitor is up and “+” direction when it is down. 9 / 12...
- Page 10 Connect cables Type-C Host（PC） 10 / 12...
- Page 11 Using cord management Use both hands to pull apart the cable holder to remove. Once cords are in place, put the cable holder back in place. holder, 11 / 12...
- Page 12 WARNING This product was designed to be installed on desk.Before installing, make sure the mount will support the combined load of the equipment and hardware.Never exceed the maximum load capacity 8.5 kg, or else it may result in product failure or personal injury. Note:this product is intended for indoor use only.Use of this product outdoors could lead to product fallure or personal injury.
