Sensor Mounting Shelf support tube holes
The following illustrations show the locations of the support tube holes in both the
black plastic and the white painted aluminum Sensor Mounting Shelf types. The instal-
lation procedure and mechanical performance of the different shelves are identical.
Three Holes for Sensor Screws
Three Holes for Sensor Screws
Product Number: 6672 and 6673
Sensor Mounting Shelf
Copyright © 2004 Davis Instruments Corp. All rights reserved.
Holes for Support Tube Screws
Aluminum Sensor Mounting Shelf support tube holes
Three Holes for Sensor Screws
Holes for Support Tube Screws
Plastic Sensor Mounting Shelf support tube holes
Three Holes for Sensor Screws
Part Number: 07395.133
Rev B Manual (October 4, 2004)
