Davis Instruments Grounding Kit Install Manual

Many of our products require a proper ground in order to function properly.
For situations where a proper ground is not available, all you need to do is
drive the grounding rod into the earth to create a ground for any of our prod-
ucts. In some cases, more than one ground rod may be required to meet specifi-
cations. Check your local codes to make sure that the grounding rod will
provide a suitable ground for your location.
C
OMPONENTS
The Grounding Kit includes the following. Please make sure you have every-
thing you need before beginning.
2 Copper-plated Rods 5/8" (1.5 cm) diameter x 32 inches (81 cm)
Coupler
Wire Clamp
T M
OOL AND ATERIALS
You will need some of the following tools and materials.
Shovel
Heavy-duty Hammer, 2.5-pound (1 kg) or heavier
Wrench
Wire Stripper or Knife
Ladder
N
EEDED
G
R O U N D I N G
K
I T
Page 1
