JOY-IT VIEW 15
15.6'' portable monitor with touchscreen
1. INFORMATION
Dear Costumer,
thank you very much for choosing our product.
In the following, we will introduce you to what has to be observe while start-
ing up and using this product.
Should you encounter any unexpected problems during use, please do not
hesitate to contact us.
The Joy-View was designed for the USB-type-C interface and inherits a
high-quality touchscreen besides the Full-HD-resolution. Many more devi-
ces like gaming consoles are supported with an additional Mini-HDMI-port.
With the enclosed smart case the Joy-View is not only protected on every
transport. Further, due to its pedestal, the case also offers a safe and upright
stand feature. In addition, the JOY-View has very low weight. That is why it
suits perfect for mobile use.
Advertisement
Table of Contents
Related Manuals for Joy-it VIEW 15
Summary of Contents for Joy-it VIEW 15
- Page 1 JOY-IT VIEW 15 15.6‘‘ portable monitor with touchscreen 1. INFORMATION Dear Costumer, thank you very much for choosing our product. In the following, we will introduce you to what has to be observe while start- ing up and using this product.
-
Page 2: Safety Instructions
2.SAFETY INSTRUCTIONS MOUNTING THE MONITOR Please make sure the monitor is placed on stable ground and no cables get in the way, otherwise there is a danger of injuries. Please consider when pla- cing the monitor on another device, this device must be able to withstand the weight of the display, otherwise this can result to damages of the device. -
Page 3: Technical Specifications
DO NOT TOUCH PLUG WITH WET HANDS In case you touch the plug with wet hands, it may lead to fire or electric shocks. 3. TECHNICAL SPECIFICATIONS Resolution 1920 x 1080 Breadth 10 mm Refresh rate 60 Hz Brightness 300 nit Contrast 800 : 1 16.7M, NTSC 72%,... - Page 4 5. FUNCTIONALITY OF BUTTONS & INTERFACES 4.HDMI 1.POWER 5.Type-C 2.+ / Menu / - 3.PD 6.Headphone jack 1. POWER Press and hold down: switching the monitor on/off Press shortly: 1. Open the signal source menu 2. Close or return in the OSD Menu 2.
-
Page 5: Color Temp
6. ON-SCREEN DISPLAY MENUE BRIGHTNESS Setting of display's brightness CONTRAST Setting of display's contrast Adjusts the brightness for an activity Rises the contrast for low display brightness H. POSITION Horizontal orientation of the image on display V. POSITION Picture adjustment to vertical image interferences CLOCK Vertical orientation of the image on display PHASE... - Page 6 7. SETTING OF THE MONITOR 1. Attach the smart case to the monitor. CAUTION: You have to fix the smart case proper to the horizontal lying monitor, other- wise it may fall over or drop. Connect the monitor with your device and connect to a power supply. Hereto, you can use different methods.
- Page 7 Connecting the Monitor with Touchscreen 1. Connect the monitor with your laptop or Raspberry Pi using the HDMI cable. 2. Connect your monitor with your laptop or Raspberry Pi also using the USB A to USB Type-C cable. raspberry pi board HDMI Mini HDMI Type-A...
- Page 8 Devices which support USB Type-C port (Examples): Game consols Nintendo Switch Tablet Huawei Mate 10, Mate 10 Pro, Mate 20 Pro Mate 20 X, Mate 20, Mate 20 RS P20 Pro, P20, P30, P30 Pro MateBook 13, MateBook X Pro MateBook X, MateBook E Samsung Galaxy S8, Galaxy S8+, Galaxy S9...
- Page 9 We of course support you after the purchase. Should you have any questions or encounter problems, please feel free to contact us via e-mail, phone und ticket support system. E-mail: service@joy-it.net Ticket-System: http://support.joy-it.net Phone: +49 (0)2845 98469 – 66 (10 - 17 o'clock) For further information, please visit our website: www.joy-it.net...
