PXN2770MW
LED LCD Monitor
USER'S GUIDE
www.planar.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PXN2770MW and is the answer not in the manual?

Questions and answers

Related Manuals for Planar PXN2770MW

Summary of Contents for Planar PXN2770MW

  • Page 1 PXN2770MW LED LCD Monitor USER'S GUIDE www.planar.com...

  • Page 2: Table Of Contents

    Content Operation Instructions Thank you for purchasing the PXN2770MW LED LCD monitor. Please read this guide thoroughly Operation Instructions..............................1 before installation. Unpacking Instructions ..............................3 FCC RADIO FREQUENCY INTERFERENCE STATEMENT Safety Precautions................................3 WARNING: (FOR FCC CERTIFIED MODELS) Consignes de sécurité ..............................4 Package Overview .......................
  • Page 3 COMMUNIQUE D’AVERTISSEMENT DE LA FCC CONCERNANT LES INTERFERENCE DE FREQUENCE RADIO: (SEULEMENT POUR MODELES CERTIFIE PAR LA FCC) Ce moniteur a été testé et à été trouvé conforme aux limites pour un appareil numérique de Classe B, suivant la partie 15 des règlements de la FCC. Ces limites ont été développées pour o rir une protection satisfaisante contre les interférences nuisibles dans une installation résidentielle.

  • Page 4: Unpacking Instructions

    Unpacking Instructions Remove the LED LCD Monitor out of the package and take o the plastic bag and Polystyrene Foam. Remove base from plastic bag and attach to base. Adjust the display between -5° and 20°. Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit.

  • Page 5: Consignes De Sécurité

    Consignes de sécurité Respectez tous les avertissements, les précautions et conseils d’entretien recommandés dans ce manuel de l’utilisateur pour maximiser la durée de vie de votre appareil. A faire : Éteindre le produit avant de le nettoyer. La surface de l'écran tactile peut être nettoyée avec un chi on doux et propre imprégné d’un nettoyant doux du commerce pour vitres ou d'un mélange à...

  • Page 6: Package Overview

    Package Overview LED LCD Monitor Stand Base Power Cord VGA Cable Display Port Cable Audio Cable User’s Guide...

  • Page 7: First Setup

    First Setup Install the stand base 1. Lay the LED LCD Monitor at on a table with the LED screen face down. To prevent the LED LCD Monitor from being scratched, put a piece of soft cloth on the table on which the screen will be set.

  • Page 8: Front View Of The Product

    Front View of the Product OSD Turn On/ O Scroll Down/ Adjust Decrease/ Brightness/ Auto * Scroll UP/ Adjust Increase/ Blue Light Reducer * Input select/ Con rm Selection Power On/ O LED Indicator * Hot keys Instructions please see “Using the OSD Menu” on page 10.

  • Page 9: Rear View Of The Product

    Rear View of the Product Power Input DisplayPort Input (DisplayPort 20 pin) HDMI input (HDMI 19 pin) VGA Input (D-Sub 15 pin) Audio Input Headphone Jack...

  • Page 10: Quick Installation

    Quick Installation Connect either VGA, HDMI or DisplayPort Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. Please note. The monitor ships with DisplayPort and VGA cables only. HDMI cable may be sourced separately from a cable supplier.

  • Page 11: Basic Operation And Calibration/Reset Instructions

    Basic Operation and Calibration/Reset Instructions Before using the LED LCD Monitor: Connect external equipment properly. Insert the power plug, and the power LED indicator will light orange. Power On/O To turn the LED LCD Monitor on/o : Press button on the front. The power LED indicator light will be blue when the LED LCD Monitor is on.
  • Page 12 Option 2: OSD & Power button lock – all 5 buttons including the “POWER” button are locked. Press and hold the 1 button and the button for 3 seconds to lock all 5 buttons. The LED LCD Monitor will show a “Power Button Locked” message for 3 seconds and the message will disappear automatically.

  • Page 13: Advanced Operation-Osd Menu

    Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your LED LCD Monitor. Press the 1 button to display the OSD Menu, and use to select the desired OSD menu. Short Cuts Function from the button(s) AUTO IMAGE ADJUST: To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H.
  • Page 14 OVER DRIVE: Allows the user to change the Over Drive strength. Improve the quality of the motion pictures. INPUT SELECT: When Input Select is pressed, change Input signal to VGA, HDMI, DISPLAYPORT or AUTO. AUDIO ADJUST: To adjust the audio functions. VOLUME: To adjust the volume of speaker output.
  • Page 15 H./V. POSITION: To adjust the horizontal and vertical position of the video. HORIZONTAL POSITION: : move screen to the right, : move screen to the left. VERTICAL POSITION: : move screen up, : move screen down. HORIZONTAL SIZE: To adjust the width of the screen image. : increase the width of screen image, : decrease the width of screen image.

  • Page 16: Supporting Timing Modes

    Supporting Timing Modes STANDARD RESOLUTION 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA...

  • Page 17: Technical Information

    Technical Information Panel 27” TFT (with LED backlight) Power Management Normal On: 32 Watts (typical), 40 Watts (maximum) ECO Mode 1 On: 27.3 Watts (typical) ECO Mode 2 On: 23 Watts (typical) ECO Mode 3 On: 17.4 Watts (typical) Standby Mode: < 0.5 Watt O : <...

  • Page 18: Wall-Mount Installation Instructions

    Wall-Mount Installation Instructions Preparing to Install the Optional Wall Mount Arm (not included) This LED LCD Monitor can be attached to a wall mounting arm purchased separately. Turn the power OFF then disconnect the cables from the LED LCD Monitor before performing the procedure below. 1.

  • Page 19: Troubleshooting

    Troubleshooting No power Make sure A/C power cord is securely connected to the power adapter and the power supply is rmly connected to the LED LCD Monitor. Plug another electrical device into the power outlet to verify that the outlet is supplying proper voltage.

  • Page 20: Planar Support

    Planar Support Cables and Accessories To nd cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com. Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touchscreen drivers, warranty information and access to Planar's Technical Library for online trouble shooting.
  • Page 21 Hours: 24 hours a day, 7 days a week 03/2020 Planar Systems, Inc. © Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
