- Page 1 ® ® COMMERCIAL & DOMESTIC COMMERCIAL & DOMESTIC PALLAS ENJOY SMART MANUAL...
- Page 2 DEAR CUSTOMER, Water Treatment Systems use Reverse Osmosis System which is one of the advanced technologies in the world. Water Treatment Systems have been designed to remove physical, chemical and microbiological pollutants in water and to produce water in drinkable quality. Water Treatment Systems not only produce drinkable water but also produce water in best quality for meeting the needs of domestic...
-
Page 3: Table Of Contents
GENERAL INFORMATION ..................4 PURIFICATION STAGES IN UNDERCOUNTER REVERSE OSMOSIS SYSTEM ..5 WORKING PRINCIPLE ....................5 POINTS TO BE CONSIDERED BEFORE INSTALLATION OF THE DEVICE ....6 BOX CONTENTS AND ASSEMBLY PARTS..............7 DEVICE PROPERTIES ....................8 INSTALLATION AND ASSEMBLY ................. 9 MAINTENANCE AND CLEANING ................ -
Page 4: General Information
GENERAL INFORMATION What is REVERSE OSMOSIS? Reverse osmosis practices Osmosis is a process in which water passes th- Water treatment device is designed to work with rough a semi-permeable membrane from a less minimum water pressure. It does not require che- concentrated solution into a more concentrated mical use and produces quality water. -
Page 5: Purification Stages In Undercounter Reverse Osmosis System
ION REMOVAL IN REVERSE OSMOSIS ION AND ORG. PESTICIDE REMOVAL ( % ) ION AND ORG. PESTICIDE REMOVAL ( % ) Aluminum 97-98 Nickel 97-99 Ammonium 85-95 Nitrate 93-96 Arsenic 94-96 Phosphate Magnesium 96-98 Potassium Bicarbonate 95-96 Radioactivity 95-98 Bromide 93-96 Radium Cadmium... -
Page 6: Points To Be Considered Before Installation Of The Device
POINTS TO BE CONSIDERED BEFORE INSTALLATION OF THE DEVICE Water treatment system’s operating water tempe- If the device is used beyond the limit values men- rature is between minimum 5˚C (41˚F) and maxi- tioned in technical specification part of the users’ mum 40˚C (104˚F). -
Page 7: Box Contents And Assembly Parts
MANUAL BOX CONTENTS AND ASSEMBLY PARTS Metal Ball Valve 1/4” Reverse Osmosis Device 75 GPD Dynamic Pump Faucet (available in model with pump) 12” Inline Block Carbon Cartridge Filter (CTO) 24 Volt 1,5 Amper Adapter 12” Gac Carbon Cartridge Filter (UDF) (available in model with pump) 10”... -
Page 8: Device Properties
DEVICE PROPERTIES TECHNICIAL SPECIFICATIONS WITH PUMP WITH OUT PUMP Min. Operating Water Temperature 5 °C 5 °C Max. Operating Water Temperature 40 °C 40 °C Min. Inlet Pressure 1 bar 3 bar Max. Inlet Pressure 6 bar 6 bar Max. Inlet TDS (ppm) 500 ppm 500 ppm Inlet Diameter... -
Page 9: Installation And Assembly
MANUAL INSTALLATION AND ASSEMBLY HOW TO ASSEMBLE SINGLE BATTERY WATER INTAKE DOUBLE BATTERY WATER INTAKE WATER INTAKE IN UNDER COUNTER Extension 3-way adapter 3-way adapter 1/4 Ball Valve 1/4 Ball Valve FIGURE A-2 1. Before the installation, turn off the valve of main feedwater line orthe inlet valve. - Page 10 MEMBRANE INSTALLATION 12” Inline 5 Micron Spun (Sediment) Filter 12” Inline Gac Carbon Cartridge Filter (UDF) 12” Inline Block Carbon Cartridge Filter (CTO) 75 GPD Membran 10” Inline Coconut Post Carbon Filter • After intalling the filters, unscrew membrane housing cap.
-
Page 11: Maintenance And Cleaning
START-UP AFTER INSTALLATION Once you have assembled and installed all the !! IMPORTANT !! components, turn on the water supply first tocheck for leaks.Then, turn on the faucet slowly. At the first *During the first few days after installation, air bubbles stage, water will run from the faucet slowly. - Page 12 INSTALLATION AND REPLACEMENT OF MEMBRANE WASHING PROCEDURES 1. Open the tube union of 3rd housing and dischar- 1. Disconnect the plug from the socket. ge the water supplied to Sedimentfilter, Activa- 2. Turn off the water supply valve. ted Carbon filter and BlockCarbon filter. Perform 3.
- Page 13 REPLACEMENT OF POST CARBON FILTER Turn off the water supply and open drinking wa- Water inlet direction Water outlet direction ter faucet. Loose tubing unions at inlet and outlet and dis- Flow card the used post-carbon. Disconnect the union placed at the outlet of the filter.
-
Page 14: Start-Up After Maintenance
START-UP AFTER MAINTENANCE TRANSPORTATION AND HANDLING After turning on the valves, turn on the water supp- ly. Open RO faucet and check the entire system for At first, follow the occupational safety rules. leaks. Drain the water in the tank before transportation Now you can enjoy the quality water safely. -
Page 15: Warranty Conditions
WARRANTY CONDITIONS Damages or defects due to natural disasters. EXCLUSIONS FROM THIS WARRANTY Damages or defects resulting from running the The warranty excludes defects caused by the misu- device with water below 5oC degrees and above se of water treatment device. The consumer should 40oC degrees. -
Page 16: Important Safety And Environmental Instructions & Consumer Rights
IMPORTANT SAFETY AND ENVIRONMENTAL INSTRUCTIONS & CONSUMER RIGHTS INFORMATION ON POTENTIAL HAZARDS FOR RIGHT OF CHOICE PROVIDED TO CONSUMER ENVIRONMENT AND HUMAN HEALTH DURING WITH 11th ARTICLE OF LAW OPERATION 1. If the product is found defective; Consumer can renege on the contract by notif- ... -
Page 17: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Action No water supply Ceck if water enters the system Faulty connection to power Check the electrical connections THE DEVICE DOES source NOT WORK Damaged adapter Replace it or contact service Faulty low pressure switch Replace it or contact service Water supply valve is closed Open the water supply valve NO PRODUCT (PURIFIED) -
Page 18: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS “How often should filters be replaced?”” “I do not often use the system, does it change life span of filters and membrane?” It depends on properties, quality of water supply and usage frequency of the system. It is recom- Replacement dates of the first three filters do not mended to replace filters every six months. - Page 19 WARRANTY This document is allowed to be used by Directorate General of Consumer Protection and Market Surveillance, Republic of Turkey Customs and Trade Ministry in accordance with the Regulation of Practice Principles of warranty Certificate that is implemented by depending on Consumer Protection Law Numbered 6502 MANUFACTURER AND IMPORTER : ESLİ...
- Page 20 The product you have purchased complies with the standards of 2014/35/EU; DECLARATION OF CONFORMITY We hereby declare that we manufacture the products in compliance with the requirements of Low Voltage Directive 2014/35 / EU as described below. Product : ENJOY SMART Models : WITH PUMP Conformity...
