Summary of Contents for Pallas VIVA 5T
- Page 1 ® ® COMMERCIAL & DOMESTIC RO COMMERCIAL & DOMESTIC RO ® PALLAS VIVA 5T MANUAL...
- Page 2 DEAR CUSTOMER, Water Treatment Systems use Reverse Osmosis System which is one of the advanced technologies in the world. Water Treatment Systems have been designed to remove physical, chemical and microbiological pollutants in water and to produce water in drinkable quality. Water Treatment Systems not only produce drinkable water but also produce water in best quality for meeting the needs of domestic...
-
Page 3: Table Of Contents
GENERAL INFORMATION .....................4 PURIFICATION STAGES IN UNDERCOUNTER REVERSE OSMOSIS SYSTEM ....5 WORKING PRINCIPLE ....................5 POINTS TO BE CONSIDERED BEFORE INSTALLATION OF THE DEVICE ......6 BOX CONTENTS AND ASSEMBLY PARTS ..............7 DEVICE PROPERTIES ....................8 INSTALLATION AND ASSEMBLY ...................9 MAINTENANCE AND CLEANING ..................11 START-UP AFTER MAINTENANCE ................14 WARRANTY CONDITIONS ...................15 IMPORTANT SAFETY AND ENVIRONMENTAL INSTRUCTIONS &... -
Page 4: General Information
Design of the reverse osmosis systemrequires va- and original parts supplied byan authorized service rious technical knowledge and experience such as must be used. product water quality,raw water analysis, type of membrane etc. | Viva 5T - with or without pump... -
Page 5: Purification Stages In Undercounter Reverse Osmosis System
ION REMOVAL IN REVERSE OSMOSIS ION AND ORG. PESTICIDE REMOVAL ( % ) ION AND ORG. PESTICIDE REMOVAL ( % ) Aluminum 97-98 Nickel 97-99 Ammonium 85-95 Nitrate 93-96 Arsenic 94-96 Phosphate Magnesium 96-98 Potassium Bicarbonate 95-96 Radioactivity 95-98 Bromide 93-96 Radium Cadmium... -
Page 6: Points To Be Considered Before Installation Of The Device
TREATMENT DEVICE FLOW SCHEME Bacteria Flora Virus Lead Treated water Waste water Raw water entrance 5 Micron black Granular activated 5 Micron carbon filter carbon filter sediment filter | Viva 5T - with or without pump... -
Page 7: Box Contents And Assembly Parts
MANUAL BOX CONTENTS AND ASSEMBLY PARTS Reverse Osmosis Device 75 GPD Membrane Star Faucet Metal Ball Valve 10” Housing (Double O-ring) Pump 10” White Housing (Double O-ring) Adapter 10” Block Carbon Cartridge Filter (CTO) Tube 10” GAC Carbon Cartridge Filter (UDF) Feed water Connection Adapter 10”... -
Page 8: Device Properties
36,5 x 50 x 19 (P160 Model) 35 x 44,5 x 14,5 (S170 Model) NOTE: The equipments used in the product are in compliance with Water Quality, CE and NSF standards. The equipments are certified. | Viva 5T - with or without pump... -
Page 9: Installation And Assembly
MANUAL INSTALLATION AND ASSEMBLY HOW TO ASSEMBLE SINGLE BATTERY WATER INTAKE DOUBLE BATTERY WATER INTAKE WATER INTAKE IN UNDER COUNTER Extension 3-way adapter 3-way adapter 1/4 Ball Valve 1/4 Ball Valve FIGURE A-2 1. Before the installation, turn off the valve of main feedwater line orthe inlet valve. - Page 10 Ÿ C: The tube at the outlet of post carbon is conne- cted to product water line. TANK Ÿ D: The drain tube is connected to wastewater WASTEWATER outflow line. WATER INLET | Viva 5T - with or without pump...
-
Page 11: Maintenance And Cleaning
START-UP AFTER INSTALLATION Once you have assembled and installed all the !! IMPORTANT !! components, turn on the water supply first tocheck for leaks.Then, turn on the faucet slowly. At the first *During the first few days after installation, air bubbles stage, water will run from the faucet slowly. - Page 12 The children must not play with the device. The maintenance must not be carried out by the children Do not forget to connect the power plug to the socket in models without observance of an adult. with pump. | Viva 5T - with or without pump...
- Page 13 REPLACEMENT OF POST CARBON FILTER Ÿ Turn off the water supply and open drinking wa- Water inlet direction Water outlet direction ter faucet. Ÿ Loose tubing unions at inlet and outlet and dis- Flow card the used post-carbon. Ÿ Disconnect the union placed at the outlet of the filter.
-
Page 14: Start-Up After Maintenance
10 (ten) years from the delivery date. The warranty is applicable only to defects in the device and we are not responsible for any other cost. No claim of indemnity can be made under any other name. | Viva 5T - with or without pump... -
Page 15: Warranty Conditions
WARRANTY CONDITIONS EXCLUSIONS FROM THIS WARRANTY Ÿ Damages or defects due to natural disasters. Ÿ Damages or defects resulting from running the The warranty excludes defects caused by the misu- device with water below 5oC degrees and above se of water treatment device. The consumer should 40oC degrees. -
Page 16: Important Safety And Environmental Instructions & Consumer Rights
| Viva 5T - with or without pump... -
Page 17: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Action No water supply Ceck if water enters the system Faulty connection to power Check the electrical connections THE DEVICE DOES source NOT WORK Damaged adapter Replace it or contact service Faulty low pressure switch Replace it or contact service Water supply valve is closed Open the water supply valve NO PRODUCT (PURIFIED) -
Page 18: Frequently Asked Questions
The warranty peri- od of the product is 2 (two) years. You can contact us within this period in case of any dispute, damage or defect not resulting from misuse; | Viva 5T - with or without pump... - Page 19 PRODUCT TYPE : WATER TREATMENT DEVICE BRAND : Pallas MODEL : Viva 5T - with or without pump WARRANTY : 2 YEARS MAX. REPAIR TIME : 20 WORK DAY BANDEROL AND SERAL NO DEVICE LIFETIME: WATER TREATMENT DEVICE HAS 10 (TEN) YEARS LIFETIME. Purchased product has 2 (two) years of warranty.
- Page 20 We hereby declare that we manufacture the products in compliance with the requirements of Low Voltage Directive 2014/35 / EU as described below. Product : Viva Models : Viva 5T - with pump Conformity Assessment Method : 2014/35/EU Applicable CE Directives (2014/35/EU)
