Digital Watchdog Star-Light Plus DWC-B7553WTIR User Manual page 12

Installation - Disassemble the camera
Before installing your camera, read the following cautions.
1. The mounting surface must withstand five times
the camera weight.
2. Do not let the cables get caught in improper
places or the electric line cover can be damaged.
This may cause a short or fire.
3. When installing your camera, do not allow any
person to approach the installation site. If you
have any valuable things under the place, move
them away.
Using the mounting template or your camera,
1
mark and drill the necessary holes to mount the
bracket to a wall or ceiling.
Pull a necessary wires through and make the
2
proper connections. See pages 14-15.
Use the four mounting screws to install the
3
camera on the wall or ceiling. See page 16 for
tilting and pan adjustment options.
12
