Dear Grady-White Owner:
Welcome aboard!
Buying and owning a boat is a very special experience. Of all the many products you'll ever
own we want your Grady-White experience to be the absolute best. That means providing the
descriptions, explanations and technical support that you need to enjoy your Grady-White with
confidence and security.
Your Grady-White exceeds all US Coast Guard safety standards and is built to standards
certified by the National Marine Manufacturers Association (NMMA). Best of all, your boat is
built to Grady-White standards, standards that have served our owners through some truly
extraordinary conditions since our first models built in 1959.
The seaworthiness and safety of your Grady-White is highly dependent on the operation,
maintenance and care of your boat, so please read this manual thoroughly and keep it around for
reference. If you need further explanation or "hands-on" help, don't hesitate to ask the people at
your Grady-White dealership; they have experience with the systems and operations of your boat.
If for any reason you need additional help, please feel free to call us at the factory. We sincerely
want to provide you with the help and information that will make your Grady-White experience
delightful.
Thanks for choosing a Grady-White. All of us at the factory and at your dealership are
dedicated to earning your confidence in Grady-White Boats. Again, welcome aboard.
Sincerely yours,
Kris Carroll
President
Grady-White Boats, Inc.
5121 Martin Luther King Jr. Hwy, Greenville, NC 27834 • P.O. Box 1527 • Greenville, NC 27835-1527
Tel: 252-752-2111 • Fax: 252-752-4217 • http://www.gradywhite.com
Grady-White Boats, Inc.
Advertisement
Table of Contents
Related Manuals for Grady-White Boats COASTAL EXPLORER 251
Summary of Contents for Grady-White Boats COASTAL EXPLORER 251
- Page 1 Grady-White experience delightful. Thanks for choosing a Grady-White. All of us at the factory and at your dealership are dedicated to earning your confidence in Grady-White Boats. Again, welcome aboard. Sincerely yours, Kris Carroll President Grady-White Boats, Inc.
-
Page 3: Table Of Contents
A B L E O F O N T E N T S 1 : C H A P T E R O N S U M E R N F O R M A T I O N Owner’s Packet ........1–1 Warranty Information . - Page 4 A B L E O F O N T E N T S 5 : I H A P T E R N S T R U M E N T A T I O N A N D W I T C H E S Yamaha Instrumentation Panel .
- Page 5 A B L E O F O N T E N T S Canvas ..........8–1 O p e r a t i o n O f S t a n d a r d F e a t u r e s .
- Page 6 A B L E O F O N T E N T S...
-
Page 7: Information
• A warranty card to be completed and signed by the dealer and the customer. This warranty card is to be sent to Grady-White Boats to validate the warranty. • An explanation of safety issues regarding the use of containment systems and components. -
Page 8: Consumer Responsibilities
• Return the boat to the selling dealer for an engine inspection. Refer to the engine’s owner’s manual for the proper maintenance schedule. Grady-White Boats has a permanent record of your boat which is retained under its “Hull Identification Number” (HIN). Data regarding equipment and accessories, as well as dealer/ shipping information is documented. -
Page 9: Hazard Warning Labels
E L C O M E AZARD ARNING ABELS The hazard warning labels shown below are applied throughout this manual to alert the customer of potentially dangerous situations that can lead to death, personal injury, and/or product damage. We urge you to observe these warnings and comply with all safety recommendations. D A N G E R This symbol alerts you to imminently hazardous situations which WILL cause severe personal injury or death if the warning is ignored. - Page 10 E L C O M E 1–4...
-
Page 11: A F E T Y
USCG approved visual distress signals are required on U. S. waters. See page 42 of the pamphlet Sportfish, Cruisers, Yachts Owner’s Manual enclosed with this manual for more information. • Lighting Grady-White boats are equipped with navigational lights that meet requirements for recreational vessels for inland and international waters. DDITIONAL ECOMMENDED... -
Page 12: Emergency Stop Switch
A F E T Y MERGENCY WITCH All Grady-Whites are equipped with an emergency stop switch. This is a safety feature that if used properly will shut the engine(s) down if the operator leaves or falls from the helm position. The ignition shutdown system includes a shut-off switch, switch clip, lanyard and lanyard clip. -
Page 13: Boating Safety Tips
A F E T Y OATING AFETY Safety is an important aspect of boating. Your safety as well as the safety of your passengers and vessel is your responsibility. The following precautions and the ones mentioned in section 1 of Sportfish, Cruisers, Yachts Owner’s Manual will add to you and your passengers’ boating safety and pleasure. -
Page 14: Certification
A F E T Y ERTIFICATION This label means your Grady-White is certified by the National Marine Manufacturers Association (NMMA). With this tag, you are assured the fuel system, electrical system, navigation lighting, ventilation, steering and other design elements are not only in compliance with the US Coast Guard regulations, but also meet the more stringent standards of the NMMA. -
Page 15: Loading Capacity
Allow yourself an extra margin in rough waters and adverse conditions by reducing the boat’s capacity. Maintain a watch on weather conditions. 1650 MEETS U.S. EPA EVAP STANDARDS USING CERTIFIED COMPONENTS GRADY-WHITE BOATS, INC. COASTAL EXPLORER 251 GREENVILLE, NC NATIONAL MARINE MANUFACTURERS ASSOCIATION ABYC... -
Page 16: Designated Occupant Positions
A F E T Y ESIGNATED CCUPANT OSITIONS The number of designated occupant positions matches the persons capacity label of your boat. These areas may be standing or seating positions that are appropriately sized and designed to be safely occupied at boat speeds in excess of 5 mph (4.3 knots). -
Page 17: Carbon Monoxide
A F E T Y ARBON ONOXIDE W A R N I N G CO is produced by all combustion engine(s) and generator sets. Avoid brain damage or death from carbon monoxide. Keep cockpit and cabin areas well ventilated. Avoid blockage of exhaust outlets. Signs of exposure include headache, nausea, dizziness and drowsiness. -
Page 18: Suggested Boating Classes And Reading Material
A F E T Y UGGESTED OATING LASSES EADING ATERIAL Like a car, boats must be operated according to safety rules and traffic regulations. Although we include some basic boating tips in this manual, a thorough review of the safety rules and regulations for boating is beyond the scope of this text. -
Page 19: E N E R A L
E N E R A L N F O R M A T I O N C h a p t e r 3 : G e n e r a l I n f o r m a t i o n UELING W A R N I N G Safety during fueling requires CAUTION and COMMON SENSE. -
Page 20: Environmental Protection Agency
N F O R M A T I O N NVIRONMENTAL ROTECTION GENCY All Grady-White boats meet the Environmental Protection Agency standards in effect at the time of manufacture. All boats have the EPA label incorporated within their NMMA certification label. OLLUTION EGULATIONS The U.S. -
Page 21: Anchoring
E N E R A L N F O R M A T I O N NCHORING Some factors that determine the size and type of anchor most suitable for your boat include the size of your boat and the type of lake, sea or river bottom in your boating area. Sportfish, Cruisers, Yachts Owner’s Manual has a list of tips concerning anchoring starting on page 56. -
Page 22: Shallow Water
E N E R A L N F O R M A T I O N HALLOW ATER Most boats that become grounded can be floated off with engine(s) tilted to reduce the draft at the transom. With motors tilted, try rocking the boat from side to side to break the suction of mud from the keel. -
Page 23: Commonly Used Nautical Terms
E N E R A L N F O R M A T I O N OMMONLY AUTICAL ERMS Access Plate Port Side Beam Stern Bow Pulpit Cleat Starboard Side Gunwale Bow Eye Keel Chine Headroom - vertical distance between the floor and Abeam - a line perpendicular to a boat's keel over head structure or canopy ceiling Access Plate - a removable, watertight cover that... - Page 24 E N E R A L N F O R M A T I O N 3–6...
-
Page 25: E R F O R M A N C E
E R F O R M A N C E C h a p t e r 4 : P e r f o r m a n c e ERFORMANCE ACTORS Maximum performance is dependent on many factors and cannot be guaranteed. These factors will vary with changing conditions. -
Page 26: Propeller
E R F O R M A N C E Propeller The condition of your prop has a major influence on the performance of your boat. Your engine(s) should be equipped with the best size prop for normal conditions. Unusual uses or weight conditions may require special props. -
Page 27: Engine Warranty
• Mechanical Steering Grady-White boats that use mechanical steering are equipped with No Feedback Mechanical Steering. No feedback steering provides easier steering and increased control by offsetting the engine(s) torque. -
Page 28: Throttle/Shift Controls
E R F O R M A N C E HROTTLE HIFT ONTROLS The throttle/shift controls located at the helm station control the flow of fuel to the engine. They also act as gear shift levers to control the forward and reverse thrust of the propellers. The middle position of the throttle control is the neutral position. -
Page 29: N S T R U M E N T A T I O N A N D
N S T R U M E N T A T I O N A N D W I T C H E S C h a p t e r 5 : I n s t r u m e n t a t i o n a n d S w i t c h e s AMAHA NSTRUMENTATION ANEL... - Page 30 N S T R U M E N T A T I O N A N D W I T C H E S • Low Fuel Warning Indicator This feature indicates when the fuel level in the fuel tank(s) is becoming low by flashing the lowest bar.
-
Page 31: Switch Panel
N S T R U M E N T A T I O N A N D W I T C H E S WITCH ANEL At the helm station you will find an accessory switch panel. Not all boats are equipped with the same accessories. - Page 32 N S T R U M E N T A T I O N A N D W I T C H E S 5–4...
-
Page 33: A I N T E N A N C E A N D
A I N T E N A N C E A N D E R V I C E C h a p t e r 6 : M a i n t e n a n c e a n d S e r v i c e ENERAL The amount of maintenance required to keep your boat operating properly and to maintain the appearance is dependent on how the boat is used, amount of usage, salt or fresh water, geographic... -
Page 34: Finish/Waxing
A I N T E N A N C E A N D E R V I C E Finish/Waxing Gel-coat will age or dull naturally due to constant exposure to the natural environment and pollutants. Discolorations are shallow in depth. Factors that will affect the rate of discoloration are: the sun, pollution, old wax accumulation, and the salt content of water. -
Page 35: Bottom Paint
A I N T E N A N C E A N D E R V I C E W A R N I N G M.E.K.P. (Methyl ethyl ketone peroxide), gel-coat and acetone are flammable and hazardous chemicals that must be handled properly. Follow instructions carefully. After the gel-coat is catalyzed, it will soon heat up and put off fumes. -
Page 36: Vinyl
A I N T E N A N C E A N D E R V I C E Vinyl • Clean clear vinyl thoroughly with denatured alcohol and apply a protective layer of clear wax. Do not use paste wax, as it will turn the vinyl yellow. This process should be repeated as necessary to maintain the protective wax coating. -
Page 37: Scuppers
E R V I C E CUPPERS Grady-White boats have self-bailing cockpits meaning water on the cockpit floor drains by gravity through large aft scuppers and not into the bilge. The aft drains (scuppers) have an external scupper flap assembly that restricts the flow of water back into the boat. Inspect the flaps periodically to make sure they are free of debris. -
Page 38: Fuel System Maintenance
A I N T E N A N C E A N D E R V I C E ETAL ROTECTORS Boeshield T-9 Aluma Guard Premier Polish PMS Products Inc. Rupp Marine, Inc. Aquatech by Nautical Choice 76 Veterans Dr. 4761 Anchor Ave. -
Page 39: Fuel Tank Compartment
A I N T E N A N C E A N D E R V I C E Fuel Tank Vent Fill (Installed On Deck) (Installed On Hull Side) Stainless Clamps Vent Fuel Tank 1-1/2" Fill Hose Fill (USCG Type A2) Hull Harness Stainless Clamps Pink (Main) or Pink/White (Aux) -
Page 40: Led Lighting
A I N T E N A N C E A N D E R V I C E Batteries contain electrolytes and acids that can be harmful and volatile. They can also present an electrical hazard. When handling or servicing batteries, exercise caution and follow these guidelines. - Page 41 A I N T E N A N C E A N D E R V I C E 251 DC A CCESSORY IRING OLOR REAKER Accessory Wire Amperage Location Lights Bow Light Accessory Panel 16 ga. Gray Hardtop Dome Light Hardtop Fuseblock 16 ga.
- Page 42 A I N T E N A N C E A N D E R V I C E 6–10...
-
Page 43: I N T E R I Z A T I O N A N D
Manual for a checklist on winterizing and storage. TORAGE Grady-White boats are equipped with stern eyes and a bow eye. These eyes are for anchoring and trailering purposes, and should be inspected regularly to insure structural integrity. W A R N I N G The boat should not be lifted for storage using the bow eye;... -
Page 44: Cleaning And Lubricating The Boat
I N T E R I Z A T I O N A N D T O R A G E For outdoor storage, a canvas cover should be used to prevent “sweating”. One method is to build a frame over the boat to support the canvas. It should be a few inches wider than the boat so the canvas will clear the rails and allow passage of air. -
Page 45: Batteries
I N T E R I Z A T I O N A N D T O R A G E ATTERIES Fully charge the batteries before storing. A weak battery loses its charge more rapidly than a strong battery. Coat the battery terminals with grease to prevent corrosion. NGINES See your engine Operator’s Manual regarding the winterizing procedures. -
Page 46: Prior To Launching
I N T E R I Z A T I O N A N D T O R A G E RIOR AUNCHING Start your own personalized list of items to check and perform prior to placing your boat in the water. -
Page 47: O A S T A L E X P L O R E
2 5 1 O A S T A L X P L O R E R C h a p t e r 8 : C o a s t a l E x p l o r e r 2 5 1 S p e c i f i c a t i o n s Beam-amidship..................... -
Page 48: O P E R A T I O N O F S T A N D A R D F E A T U R E S
2 5 1 O A S T A L X P L O R E R O p e r a t i o n O f S t a n d a r d F e a t u r e s WITCH ANEL At the helm you will find an accessory switch panel. -
Page 49: Other Switches
2 5 1 O A S T A L X P L O R E R Other Switches • Trim/Tilt The trim/tilt switch is located on the throttle control. Trim changes the angle of thrust of the engine (reference “Trim” on page 4–1). Tilt raises the drive unit for trailering. •... -
Page 50: Battery Select Switch
2 5 1 O A S T A L X P L O R E R ATTERY ELECT WITCH Boats equipped with two batteries have a battery select switch to indicate which battery will be used. The switch is labeled “1”, “2”, “1+2” and “off”. In normal use alternate between the battery “1”... -
Page 51: Head
2 5 1 O A S T A L X P L O R E R Portable Head Operation 1. The upper freshwater reservoir must be filled with water prior to use. Compress the bellows pump located on the left corner of the toilet a few times to add water to the bowl. 2. -
Page 52: Trim Tabs
2 5 1 O A S T A L X P L O R E R Trim tabs are electrically and hydraulically operated. The trim tab system includes a hydraulic pump, a switch with an integrated indicator, and an auto-retract feature. The switch controls the pump which lowers and raises the trim tabs. -
Page 53: O P E R A T I O N O F O P T I O N A L F E A T U R E S
2 5 1 O A S T A L X P L O R E R O p e r a t i o n O f O p t i o n a l F e a t u r e s OCKPIT HOWER To operate the shower, the freshwater switch located on the helm switch panel must be in the... -
Page 54: Seacocks
2 5 1 O A S T A L X P L O R E R EACOCKS Ball valve seacocks are installed on the thru hulls for the livewells and the washdown. It is necessary for the seacocks to be in the “open” position for operation. The “open” position is identified by the orientation of the handle. -
Page 55: Access Plate And Rigging Tube Location
2 5 1 O A S T A L X P L O R E R I n f o r m a t i o n a l D r a w i n g s A c c e s s P l a t e A n d R i g g i n g T u b e L o c a t i o n Description 3"... -
Page 56: Dc Electrical Accessories
2 5 1 O A S T A L X P L O R E R D C E l e c t r i c a l A c c e s s o r i e s Bow Lights Blue LED Courtesy Lights Wiper Motor Mast Light... -
Page 57: Fuel System Layout
2 5 1 O A S T A L X P L O R E R F u e l S y s t e m L a y o u t Fuel Vent Fuel Fill Carbon Canister 78 Gallon (295.3 L) Fuel Tank Fuel Sending Unit &... -
Page 58: Battery Wiring With Select Switch
2 5 1 O A S T A L X P L O R E R B a t t e r y W i r i n g w i t h S e l e c t S w i t c h Battery #1 Battery #2 2 ga Black... -
Page 59: Trolling Motor Layout
2 5 1 O A S T A L X P L O R E R T r o l l i n g M o t o r L a y o u t 36 Volt Receptacle PVC In Deck PVC In Hull 60 Amp Breaker (Or Appropriate... -
Page 60: Trolling Motor Battery Wiring
2 5 1 O A S T A L X P L O R E R T r o l l i n g M o t o r B a t t e r y W i r i n g NOTE: Trolling Motor Breaker Must Be Sized Appropriately For The Trolling Motor... -
Page 61: Freshwater System Layout
2 5 1 O A S T A L X P L O R E R F r e s h w a t e r S y s t e m L a y o u t 10 Gallon Cockpit (37.9 Liter) Shower... -
Page 62: Labels And Location
2 5 1 O A S T A L X P L O R E R L a b e l s A n d L o c a t i o n WARNING ROTATING PROPELLER MAY CAUSE SERIOUS INJURY OR DEATH. SHUT OFF ENGINE WHEN NEAR PERSONS IN THE WATER. -
Page 63: Livewell Layout
2 5 1 O A S T A L X P L O R E R L i v e w e l l L a y o u t Leanbar Livewell Leanbar Livewell Overflow Drain Thru-Hull Thru-Floor Leanbar Livewell Fitting Drain Leanbar... -
Page 64: Washdown Layout
2 5 1 O A S T A L X P L O R E R Wa s h d o w n L a y o u t Washdown Outlet Raw Water Strainer Raw Water Washdown Pump Seacock 8–18... -
Page 65: Typical Livewell/Washdown System
2 5 1 O A S T A L X P L O R E R T y p i c a l L i v e w e l l / Wa s h d o w n S y s t e m To Washdown Fitting Washdown Pump... -
Page 66: Stereo System Layout
2 5 1 O A S T A L X P L O R E R S t e r e o S y s t e m L a y o u t 6" Speakers Antenna Marine Stereo 6" Speakers 8–20... -
Page 67: Thru Hull Detail
2 5 1 O A S T A L X P L O R E R T h r u H u l l D e t a i l Scupper Aft Bilge Forward Bilge Forward Fishbox Forward Console Cooler Fuel Tank Vent Lean Bar Livewell H Aft Livewell... - Page 68 2 5 1 O A S T A L X P L O R E R 8–22...
-
Page 69: Registration Of Purchase
IS TO BE SENT TO THE GRADY-WHITE FACTORY AND NO REPAIRS MADE WITHOUT SUCH WRITTEN AUTHORITY. Grady-White Boats, Inc. reserves the right to improve its product through changes in design or material without obligation to incorporate such changes on boats built prior to the implementation of respected change(s). - Page 70 I M I T E D A R R A N T Y Exclusions: This warranty specifically does not include the following: • Damage caused by abuse, negligence, vandalism, lack of maintenance, improper storage, or accident. • Any statements, representations, or warranties given by dealer or other third persons other than those provided within this warranty.
-
Page 71: Warranty Claim Procedures
Upon the discovery of a defect, the owner is to promptly contact the Grady-White dealer from whom the original retail purchaser purchased the boat who will affect the corrective action under this warranty upon prior written authorization from Grady-White Boats, Incorporated. THESE WARRANTIES ARE EXPRESSLY MADE IN LIEU OF ALL OTHER WARRANTIES. - Page 72 I M I T E D A R R A N T Y 9–4...
-
Page 73: Transferable Warranty Form
RANSFERABLE ARRANTY (Not for original owner use *) * Note: For second owner’s use in transferring remainder of 5 year hull structural warranty. Please complete the following: Hull ID: _____________________________ Boat Model: _________________________ Name: _______________________________________________________ Address: _____________________________________________________ City: _________________________________ State: __________ Zip: _______________ Home Phone: __________________________Work Phone: __________________________ Email Address: _______________________________________________________... - Page 74 If yes, where is your second home? _______________________________ _______ City State Thank you for completing this questionnaire. When we receive this information, you will automatically begin receiving our AnchorLine Newsletter. Please return this form to: Grady-White Boats, Customer Relations Dept., P.O. Box 1527, Greenville, NC 27835-1527...
