Safety Advice Attention In some countries approval is needed to set up a marquee/tent larger than 75 m2. It is your responsibility to comply with local rules and regulations and to ensure that the marquee/tent is assembled correctly. In case of bad weather conditions, it is your responsibility to ensure the marquee/tent is safely secured and that the marquee/tent does not cause damage to others.
Congratulations on your purchase of our instant shelter. This unit is a combination of excellent manufacturing and design. It is comprised of a rigid frame and a durable cover. For easy assembly, we have marked all the parts with codes, with proper installation, use and maintenance, your unit will provide many years of good and suitable service.
Maintenance and care Annually or more often, the unit should be completely inspected internally and externally to make certain the unit remains properly installed and secured .Particular attention should be paid to: Hardware-check all carriage bolts and hardware connectors to be certain they are in place and tightened.
Page 5
Part List l l a l l a l a t l l a l l a Base flange for standing legs in the front panel Upper vertical tube for front and rear door Lower vertical tube for front and rear door Bottom tensioning tube of front and back cover Pole for help opening and closing the door Door cover Stake Peg...
Page 6
Figure 1 Sketch of Model 132612 Size:W4*L8*H3.8M...
Page 7
Figure 2 Sketch of parts Part no 1, 5 pcs Part no 2, 6 pcs Part no 2A, 4 pcs Part no 3, 6 pcs Part no 3A, 4 pcs Part no 4, 20 pcs Part no 8, 4 pcs Part no 9, 4 pcs Part no 10, 4 pcs Part no 11, 4 pcs...
Page 8
Step #1 --SECURING BASE FLANGES Sit the building boxes in the chosen location. Remove all the components from packaging to ensure all components are present by checking with the Part List. Figure 3 Position of Base Flanges Begin by determining exact location of the four (4) corners of the building. Mark front edge and side-to-side width of assembly on ground.
Page 9
Step #2 --ARCH ASSEMBLY Assemble each arch on ground. Each arches consist of: One curving roof tube (Part #1) Two roof curving tube (Part #2/2A) Two curving sidewall tube (Part # 3/3A) Figure 4 the arch installation Connect the arches by Using the hexagon bolts with washers and nuts through predrilled holes in frame members.
Page 10
Step #3 --ERECTING ARCHES Figure 6 Attaching Arches to Base Flanges Begin frame assembly by erecting Front Arch into Front Corner Base Flanges. Place left frame sidewall tubing into the upright tube socket into the Left Base Flange. Place Hexagonal Bolt through base flange socket and arch sidewall tube hole.
Page 11
Step #4 --POSITION ROOF COVER As figure 8 shows, when ready to install Roof Cover, unpack cover and lay parallel to building frame on one side. Cover must be pulled over top of frame assembly without being snagged or stressed on any frame members. Use multiple ropes over top of frame as shown in picture below.
Page 12
Step #5 --TENSION COVER ON FRAME FROM SIDE-TO-SIDE As Figure 9 shows, when Roof Cover is over top of Frame Assembly, insert Cover Tensioning Tubes into pockets along both sides of Roof Cover. Centre Roof Cover over Frame assembly both side to side and front to back. Align one side of Roof Cover evenly front to back.
Page 13
Figure 10 Fastening the two ends of the Roof Cover Figure 11 Installation of the Front Cover Figure 12 Open Door Cover...
