R911310379 / 02 | Rexroth IndraControl VCP 08

Display and Operating Components

6.2.4

Function Keys/Softkeys

Electric Drives and Controls | Bosch Rexroth AG

In the editor, the key Delete deletes the character beneath the cursor.It

also deletes any selected messages from the data memory.

The key Print can be configured to activate a number of print pro-

cesses. A flashing LED indicates that a print process is in progress.

The function of function keys can be assigned as required (softkey func-

tionality). The function keys can optionally be used as direct selection

keys for menu control or to trigger a function in the controller.

The function of the soft keys is freely assignable. The function keys can

be used either as direct keys for menu control or for triggering a function

in the controller.

The identifications strips can be replaced when the operating device is

built-in or removed. Inserting the strip from the rear side of the front

plate does not influence the specified seal of the operator terminal. A

set of identification strips is supplied with the operator terminal.

For the labeling use:

Single pieces, prototypes

Small series

Large series

Label with a water-resistant pen

Copying foil (thickness <= 70 µm) with

laser print

Customer-specific labeled identification

strips

6-5
