Operating Instructions
Mulchmeister
AS 84/2 LB
From serial number:
Issued:
EN-Translation of the Original Operating Instructions
014710020001
30 January 2013, V11.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mulchmeister AS 84/2 LB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AS MOTOR Mulchmeister AS 84/2 LB

Summary of Contents for AS MOTOR Mulchmeister AS 84/2 LB

  • Page 1 Operating Instructions Mulchmeister AS 84/2 LB From serial number: 014710020001 Issued: 30 January 2013, V11.0 EN-Translation of the Original Operating Instructions...

  • Page 2: Preface

    dummy Preface Intended use The device is exclusively intended for cutting Please fill in all data referring to your device. When ordering spare parts, provide your deal- grass or similar vegetation in well maintained er with the device and engine number. areas in agriculture, forestry, and landscape conservation that are mowed at least once a Serial number:...

  • Page 3: Table Of Contents

    Contents Maintenance and cleaning ...... 17 Preface ............. dummy Preparations .......... 19 Intended use ..........Cleaning the device ....... 19 General inspection ......... 19 Explanation of the symbols ....dummy Inhalts verz eichnis Chain lubrication ........19 Symbols in the instructions ....Transmission .........

  • Page 4: Explanation Of The Symbols

    dummy Inhalts verz eichnis Explanation of the symbols Prior to any repair and mainte- nance work, pull off the spark plug connector. Symbols in the instructions In these operating instructions, the following symbols are used to denote special dangers. Warning. These symbols denote special Clean the ventilation grid! dangers.

  • Page 5: Safety Instructions

    Use gloves and avoid skin Safety instructions contact with the fuel. Get informed! For your safety, read these operating instruc- Fuel up outdoors only when the engine is cool tions with care. Familiarize yourself with the and not running. Use a filler or funnel. control elements and the proper use of the Do not spill any fuel and do not let the fuel get device.

  • Page 6: Use Caution During Operation

    Do not remove, change or override any safety Prior to mowing devices or control elements. Personal protective measures Observe the maintenance instructions and replace damaged or worn parts immediately. While mowing, always wear sturdy footwear with good grip, Have an authorised service centre check your long trousers, and gloves.

  • Page 7: When Work Is Completed

    Mowing surfaces with fire hazard Be extremely cautious when turning the device round or pulling it toward you and when mov- – Carry a sufficient amount of suitable extin- ing in reverse. guishing agent. – If side inclination is too great, fuel may leak Always walk slowly! from the carburetor or the tank.
  • Page 8 – when changing a part, our original parts or parts authorised by use were not used. – the repair work was not carried out by an leer er Abs atz authorised service station. leer er Abs atz The same applies for spare parts and accesso- ries.

  • Page 9: Device Description

    Device description Steerable front wheel Type plate Air filter Oil dipstick Starter grip Fuel valve Height adjustment of handlebar Switching lever Handlebar console 10 Lever for lateral adjustment of handlebar 11 Tank ventilation 12 Tank filler spout 13 Ventilation grid 14 Spark plug connector (2 connectors) 15 Choke 16 Silencer...

  • Page 10: Control Elements

    Blade clutch lever (3 ) Control elements The blade clutch lever is a safety device. When you release the lever the blade comes to a standstill within 7 seconds Engaging blade (I): Lift the blade clutch lever, engage the latch knob (8) and press the blade clutch lever towards the handlebar.

  • Page 11: Assembly

    Steering brake levers (6) Choke Use the two steering brake levers to control Close the choke for cold engine start. the travel direction of the device. Opening the choke: Swivelling to the right: Push the wire ring inward. Press the right lever to- Closing the choke: ward the handlebar.

  • Page 12: Guide Bar And Handlebar

    Guide bar and handlebar Transport Warning! Risk of injury due to the heavy weight of the device. The device can fall over and fall down and cause severe injuries. Observe the following notices. Transport the device on a freight vehicle or a trailer which is designed for a carrying capacity of at least as great as the empty weight of the device.

  • Page 13: Unloading The Device

    To keep the area well maintained, mow fre- quently and keep the grass short. Only mow with a sharp and undamaged blade. Have the blade sharpened and balanced regularly (by authorised service centre). Do not mow when the grass is wet or when it is raining.

  • Page 14: Tanking Up

    Tanking up Danger! Fuel is ignited by hot engine parts. Prior to filling up, switch off the engine and wait for at least 20 minutes until the engine has cooled down. Observe the safety instructions regarding the fuel! Filling in the fuel: 1.

  • Page 15: Engaging The Blade

    6. Put the accelerator lever to medium engine 2. Press the drive lever towards the handlebar speed position. - device is moving. 7. With your left thumb, press the start button Drive off: and continue to hold. 1. Release the drive lever. 8.

  • Page 16: Switching Off And Parking

    Moving straight ahead: – If both steering brake levers are in rest position, both wheels rotate at the same speed. Stopping: – If both steering brake levers are pulled, the device stops. Turn the device only on already mowed grass. leer er Abs atz Switching off and parking leer er Abs atz...

  • Page 17: Maintenance And Cleaning

    Maintenance and cleaning warranty. Operational safety is endangered as Regular maintenance keeps your device ready well. for use. Contact your authorised service centre for If you do not observe the maintenance notices, checkup if you detect problems during mainte- faults may occur that are not covered by the nance.
  • Page 18 Component Action Maintenance interval ■ ▲ Chassis and Check for rust and fissures and check the welding seams. impact protec- ■ ▲ Are all protective device fastened correctly and properly func- tion tioning? ■ ▲ Label Condition of the labels. ■...

  • Page 19: Preparations

    Chain lubrication Preparations Prior to all maintenance and cleaning work: 1. Let the device cool down for at least 20 minutes. 2. Pull off the two spark plug connectors. 3. Close the fuel valve and the tank ventila- tion. 4. For work on the bottom of the device, tilt the device backwards until the engine sup- port rests on the ground.

  • Page 20: Checking The Engine Oil Level

    - cooling fins of the engine For this, observe the attached operating in- clean at all times. structions of the engine. Checking the engine oil level Checking the drive 1. Put the device on a non-slip surface (e.g. Never allow the oil level to be too low other- concrete or asphalt).

  • Page 21: Checking The Blade

    Blade change Checking the blade Danger! Improperly mounted and main- tained blades pose a severe injury hazard. Work at the blade shall only be performed by an authorised service centre. Work on the blade requires special qualifica- tions because an unbalance test is required and the torques must be observed.

  • Page 22: Longer Storage

    Also observe the notices on storage in the void for the foreign part and for the device and attached operating instructions by the engine for any resulting damage. manufacturer. Inform your authorised service centre about the device type and serial number of your devices when you order spare parts.

  • Page 23: Warranty

    Warranty The conditions of the warranty can be found on the reverse side of your warranty card. Send the filled-out warranty card immediately after the purchase of your device to “AS-Motor Germany” or the supplier. Other- wise, the warranty is no longer valid. Preserve the proof of purchase or the warranty card that was filled out by the vendor.

  • Page 24: Troubleshooting

    Troubleshooting You can find an authorised service centre on The following table contains the most frequent our home page www.as-motor.de. problems and their elimination. If more prob- lems occur, contact the closest authorised service centre. Problem Possible cause Remedy Engine does not Engine stop switch is set to Switch the engine stop switch to ON.
  • Page 25 Problem Possible cause Remedy Fuel is poor quality, dirty, or Clean the fuel system (authorised old. service centre). Always use fresh fuel. Engine starts badly Choke is closed. Open choke. or runs irregularly Air filter is soiled. Maintain air filter (see also Mainte- nance and cleaning).
  • Page 26 Problem Possible cause Remedy Oil level in the engine is too Refill engine oil (see operating in- low. structions of the engine manufactur- er). Cooling fins of the engine are Have cooling fins cleaned by author- dirty. ised service centre. Uneven cut, lawn Blade is dull or worn.

  • Page 27: Technical Data

    Technical data Type AS 84/2 LB Range of application (temperature) 0 - 30 °C For temperatures below 5 °C, observe the engine manufacturer’s information regarding the engine oil. Engine, type Two cylinder four stroke engine Manufacturer Briggs & Stratton Type 30 Vanguard, V-Twin Cylinder capacity 480 cm...

  • Page 28: Declaration Of Conformity

    Declar ati on of c onfor mity AS-Motor Germany GmbH & Co. KG Ellwanger Straße 15 D-74424 Bühlertann www.as-motor.de Declaration of conformity We declare that the lawnmower type AS 84/2 LB with serial number starting from 014710020001 as brought into circulation by us conforms to all relevant 2006/42/EG safety and health requirements of the EC directives 2004/108/EG...
  • Page 29 Umbruc h...
  • Page 30 Umbruc h...
  • Page 31 Umbruc h...
  • Page 32 Mar keti ng AS-Motor Germany GmbH & Co. KG Ellwanger Straße 15 D-74424 Bühlertann www.as-motor.de Professional technology for gardens and landscapes Allmäher® Manoeuvrable meadow mower for extensive green area care. The Allmäher reliably shreds metre-high grass, undergrowth, and weeds. Ride-on Allmäher® Ease of use and high area coverage all combined in a compact ride-on mower.
