QTech QT290 User Manual page 14

26
Fluid
Manifold
Manifold Filter Quick reference
MESH/COLOUR CODE
15 mesh / grey QF0571030
60 mesh / black QF0571060
100 mesh / blue QF0571100
200 mesh / red QF0571200
ITEM PRODUCT CODE DESCRIPTION
101
Quick ref table MANIFOLD FILTER
102
12-290-070 FILTER CAP
103 12-001 PACKING NUT TOMMY BAR
104 12-290-085 HIGH PRESSURE HOSE (1/4"-18UNF)
105 12-290-074 PRESSURE TRANSDUCER (110V&220V)
106 12-003 OUTPUT NIPPLE (PT 1/4" x 1/4"-19PF)
107 12-290-071 FILTER HOUSING
108
12-290-075 PRIMING VALVE
109
12-016 DRAIN TUBE (PT1/8"x0.45M)
110 12-290-078 SOCKET SET SCREW (PT1/4')
111 12-290-079 HEX NUT (M5-P0.8)
112 12-290-080 BRACKET
QTech QT290 Airless Sprayer
Frame
QTY
1
1
ITEM PRODUCT CODE DESCRIPTION
1
120 12-290-160
1
121 12-290-153
2
122 12-290-152
1
123 12-290-12-9
1
124 12-290-12-8
1
125 12-290-12-5
1
126 12-290-12-4
4
127 12-290-12-2
1
128 12-290-12-1
129 12-290-12-0
END CAP
HEX BOLT (M6x16xP1.0)
FLAT WASHER (Ø1/4xØ32x2)
WHEEL
EXTERNAL CIRCLIP (S-19)
FRAME
FLAT HEAD MACHINE SCREW (M4x5xP0.7)
HANDLE MOUNT
ROLL PIN (Ø5x25)
HANDLE
Brought to you by Aristospray
27
QTY
2
2
2
2
2
1
4
2
2
1
