DWL-P1012
12-Port Web-Smart IEEE 802.3af
Power over Ethernet Midspan
Version 1.01
User's Guide

Advertisement

   Related Manuals for D-link DWL-P1012

No related manuals

   Summary of Contents for D-link DWL-P1012

  • Page 1

    DWL-P1012 12-Port Web-Smart IEEE 802.3af Power over Ethernet Midspan Version 1.01 User’s Guide...

  • Page 3: Table Of Contents

    Overview of this User’s Guide...1 Introduction...1 Features...2 Ports ...2 Unpacking and Installation ...3 Unpacking ...3 Setup...4 Installing the DWL-P1012 on a Desktop ...4 Installing the DWL-P1012 on a Rack...5 Connecting Network Cables...6 Power on ...7 Identifying External Components...8 Front Panel Components...8 Rear Panel ...9 LED Indicators ...10...

  • Page 4

    Discovery List ...13 Monitor List ...14 Device Setting...15 Toolbar ...16 Configuring the DWL-P1012 ...17 Login...17 Setup Menu ...20 SNMP Setting...21 PoE Setting ...25 Schedule ...27 Port Group ...29 SNTP...31 Device Status...32 System Setting ...35 RTC Time...36 Trap Setting ...38 Set Password...39 Backup Setting ...39...

  • Page 5: About This Guide

    BOUT This user’s guide provides instructions and information to aid in the installation of the DWL-P1012, most importantly how to connect the device to your network. Terms For simplicity, this documentation uses the terms “the Midspan” to refer to the DWL-P1012, and “Midspan”...

  • Page 6: Features

    Features The DWL-P1012 features include: IEEE 802.3af Power over Ethernet compliant. Provides LED indicator for System and PoE status. Eliminates the need for AC outlets, local UPS and AC/DC adapters Web based Management for System and PoE power management. Supports SNMP protocol version 1 MIB support for: RFC1213 MIB II.

  • Page 7: Unpacking And Installation

    NPACKING AND This chapter provides unpacking and installation information for the DWL-P1012. Unpacking Open the shipping carton of the DWL-P1012 and carefully unpack its contents. The carton should contain the following items: ♦ One DWL-P1012 Web Smart PoE Midspan ♦...

  • Page 8: Setup

    Installing the DWL-P1012 on a Desktop When installing the DWL-P1012 on a desktop or shelf, the rubber feet included with the DWL-P1012 should first be attached. Attach these cushioning feet on the bottom at each corner of the device.

  • Page 9: Installing The Dwl-p1012 On A Rack

    Installing the DWL-P1012 on a Rack The DWL-P1012 can be mounted in a standard 19" rack. Use the following diagrams to guide you. Fasten the mounting brackets to the DWL-P1012 using the screws provided. With the brackets attached securely, you can mount the DWL-P1012 in a standard rack as shown on the following page.

  • Page 10: Connecting Network Cables

    Connecting Network Cables As shown below, the Midspan is connected in series to an Ethernet switch/hub. The data outputs from the switch are connected to the Midspan. The Midspan delivers power over spare twisted pairs (pins 7/8 and pins 4/5) of the Category 5 cabling, without degrading the quality of data communications.

  • Page 11: Power On

    Powered Device signals the Power Source Equipment that it is ready to receive power. Power on The DWL-P1012 must be used with AC power sources 100 - 240 VAC, 50 - 60 Hz. The DWL-P1012’s power supply will adjust to the local power source automatically.

  • Page 12: Identifying External Components

    Management port: One 10/100Mbps Fast Ethernet out of band management port. LED Indicators: Comprehensive LED indicators that display the conditions of the DWL-P1012 and status of the network. A description of these LED indicators follows. Reset button: The Reset button is to reset all device settings back to factory defaults.

  • Page 13: Rear Panel

    AC power cord. Plug in the female connector of the provided power cord into this socket, and the male side of the cord into a power outlet. The DWL-P1012 automatically adjusts its power setting to any supply voltage in the range from...

  • Page 14: Led Indicators

    LED Indicators The LED indicators of the DWL-P1012 include Power, CPU, PoE status and Management port status. Refer to the appropriate section below for information on LED function and indication. System LED On (green) : This LED will light green after the Midspan is powered on to indicate the ready state of the device.

  • Page 15: Poe Port Status Led

    PoE Port Status LED Green : When a PoE powered device (PD) is connected and the port is supplying power normally. : When the PoE port fails in the following manner: PoE power circuit shortage. Power over current: over the power current of PD’s classification.

  • Page 16: Configuration

    ONFIGURATION Through the Web Browser you can configure the DWL-P1012’s PoE power management configuration. With the attached Web Management Utility, you can easily discover all DWL- P1012 units on the network, assign them IP Addresses, change the administrative passwords and upgrade firmware.

  • Page 17: Discovery List

    Discovery List This is the list where you can discover all the Web management devices on the network. By pressing the “Discovery” button, you initiate the discovery process which will find any available Web Smart devices connected to the same LAN as the PC running the Utility and list them.

  • Page 18: Monitor List

    Gateway: Shows the Gateway set of the device. View Trap: The Trap function can receive and display the events that issue SNMP traps from the DWL-P1012 in the Monitor List. There is an indicator light on the “View Trap” button. When this indicator is green, there is no new trap message.

  • Page 19: Device Setting

    Delete Item: To delete the device in the Monitor List. Note: In order to receive Trap information using the utility, the DWL-P1012 has to be configured with the appropriate Trap IP and Trap Events first.

  • Page 20: Toolbar

    Fill in the new and old passwords and press “Set” button to apply the password change immediately. Firmware Upgrade: If D-Link releases firmware to support new functions, the new firmware can be uploaded through here. Web Access: Double click the device in the Monitor List or select a device in the Monitor List and press the “Web Access”...

  • Page 21: Configuring The Dwl-p1012

    Management Utility. Configuring the DWL-P1012 The DWL-P1012 has a Web GUI interface for smart function configurations. The DWL-P1012 may be configured through a Web Browser or using the Web Smart Utility. A network administrator can manage, control and monitor the DWL-P1012 from the local LAN.

  • Page 22

    255.255.255.0. Open a Java-enabled Web Browser, preferably Internet Explorer 6.0 or above. Enter the DWL-P1012 IP address http://192.168.0.1 (the factory-default IP address setting) in the address bar location. Alternatively through the Web Management Utility, you do not need to remember the IP Address, simply select the device shown in the Monitor List of the Web Management Utility to access the device through a Web Browser.

  • Page 24: Setup Menu

    Setup Menu When the main page appears, locate the Setup menu on the left side of the screen (see Below). Click on the setup item that you want to configure or monitor. There are eight options: SNMP, PoE, Schedule, Port Group, SNTP, Status, System, RTC Time, Trap, Password, Backup Settings and Reset Settings as shown in the Main Menu screen.

  • Page 25: Snmp Setting

    SNMP defines both the format of the MIB specifications and the protocol used to access this information over the network. The DWL-P1012 supports SNMP version 1. In SNMP v.1, user authentication is accomplished using 'community strings', which function like passwords. The remote user SNMP application and the DWL-P1012 SNMP must use the same community string.

  • Page 26

    MIBs Management and counter information are stored by the Midspan in the Management Information Base (MIB). The DWL-P1012 uses the standard MIB- II Management Information Base module and Power over Ethernet MIB (RFC3621). Consequently, values for MIB objects can be retrieved from any SNMP-based network management software.

  • Page 27

    Trap authentication fail: When checked the Midspan will issue an SNMP Trap in the event of a failed login attempt. Add Trap: To create a recipient of SNMP traps generated by the DWL-P1012’s SNMP agent, press “Add Trap” button. In the SNMP Trap Set window fill in the...

  • Page 28

    System Events: Monitoring the system’s status. Device Bootup: a trap when booting up the system. Illegal Login: a trap when an incorrect password is use in a login attempt. The IP address of the source will be recorded. PoE Events: Monitoring the PoE ports status. PoE Power fail: a trap when the port’s power source is fail.

  • Page 29: Poe Setting

    Modify Trap: To modify a previously defined SNMP Trap, click on the ID parameter to enter the selected SNMP Trap to configure its community name, IP address and events. Press “Apply” to save changes. PoE Setting The PoE Setting screen shows the status of all PoE ports including PoE Enable, Power limit, Power current (Watt.), Power Voltage (V), Power current (mA.), Classification, Status, System budget power, Support total power, Remainder Power, The ratio of system power supply.

  • Page 30

    Power limit: This function allows one to manually set a port power current limitation to be given to the PD, to protect the DWL-P1012 and the connected device, the power limit function will disable the PoE function of the port when the power is over loaded.

  • Page 31: Schedule

    Select “POE System Setting” to configure the PoE System setting. System power Threshold: When the percentage of power being supplied is greater than or equal to the System Power Threshold, the DWL-P1012 will issue an SNMP trap to alert the administrator.

  • Page 32

    To add a schedule profile simply click the Add button and define the parameters of the desired schedule. To modify an existing schedule profile click on the ID number next to the schedule profile to be modified. Name: Enter a friendly name for the schedule to be defined. Active Type: Select ‘Time Setting’...

  • Page 33: Port Group

    Port Group The advanced scheduling features of the DWL-P1012 rely on a port grouping mechanism that allows one to define groups of PoE ports. These groups are then assigned to a specific schedule profile which all members of that group adhere to.

  • Page 34

    Click ‘Delete Group’ to remove an entire group. Select the check box next to the group to be deleted and click ‘Apply’ to remove.

  • Page 35: Sntp

    SNTP The DWL-P1012 is capable of updating the system time using the Simple Network Time Protocol. When a valid DNS Server address is configured the DWL-P1012 can resolve DNS names for time servers prior to synchronization. From the SNTP configuration page of the Web UI, select SNTP Server Setting to manage the list of NTP servers used to synchronize.

  • Page 36: Device Status

    Device Status Click on the “Status” hyperlink to display the device status on this screen, it will show the System Status, SNMP Settings, PoE Status, Schedule Profiles, Port Grouping, SNTP Server and Daylight Savings Time info. This page will load upon a successful login to the WebUI.

  • Page 37

    PoE Status Schedule Profiles Port Group SNTP Server...

  • Page 38

    SNTP Time Zone and DST Press “Refresh” when you need to renew the posted information.

  • Page 39: System Setting

    System Setting The System Setting includes the Web Server Port, System name, Location name, Login Timeout, IP Address, Subnet Mask, Gateway and DNS IP addresses. Through the Web Management Utility, you can easily recognize the device by using the System Name and the Location Name. The Login Timeout for the management interface is to set the idle time-out for security reasons, when there is no activity for the specified period of time during a log-in session, the session will expire and you must log-in again to access the...

  • Page 40: Rtc Time

    RTC Time The DWL-P1012 includes an integrated Real Time Clock to handle time- keeping duties in order for port scheduling to properly function. The time may be set using one of three methods: Manual Configuration, PC Time, and SNTP Synchronization.

  • Page 41

    To synchronize the DWL-P1012 with an NTP server to retrieve the current time and date select ‘SNTP Time’ from the drop down menu. The DWL-P1012 will then contact the first SNTP server in the time server list in a top-down order to update the system time.

  • Page 42: Trap Setting

    Trap Setting The Trap Setting enables the DWL-P1012 to monitor the selected Events through the Web Management Utility, configure the Trap IP Address of the manager where the trap should be sent. System Events: Monitoring the system’s Status. Device Bootup: a trap when booting up the system.

  • Page 43: Set Password

    If you forget the password, press the “Reset” button in the front panel of the DWL-P1012 for 10-15 Seconds. All current settings such as Port Settings, SNMP, etc. will be lost and the DWL-P1012 will be restored to the factory default settings.

  • Page 44: Logout

    Logout Clicking the logout Hyperlink will log you out of the web-based administrative interface. You will be redirected to the beginning log-in page.

  • Page 45: Warranty

    Link’s sole discretion. Such repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office. The replacement Hardware need not be new or have an identical make, model or part. D-Link may in its sole discretion replace the defective Hardware (or any part thereof) with any reconditioned product that D-Link reasonably determines is substantially equivalent (or superior) in all material respects to the defective Hardware.

  • Page 46

    Non-Applicability of Warranty: The Limited Warranty provided hereunder for hardware and software of D-Link's products will not be applied to and does not cover any refurbished product and any product purchased through the inventory clearance or liquidation sale or other sales in which D-Link, the sellers, or the liquidators expressly disclaim their warranty obligation pertaining to the product and in that case, the product is being sold "As-Is"...

  • Page 47

    The customer is responsible for all in-bound shipping charges to D-Link. No Cash on Delivery (“COD”) is allowed. Products sent COD will either be rejected by D-Link or become the property of D-Link. Products shall be fully insured by the customer and shipped to D-Link Systems, Inc., 17595 Mt. Herrmann, Fountain Valley, CA 92708.

  • Page 48

    D-Link, the sellers, or the liquidators expressly disclaim their warranty obligation pertaining to the product. Repair by anyone other than D-Link or an Authorized D-Link Service Office will void this Warranty. Disclaimer of Other Warranties: EXCEPT FOR THE LIMITED WARRANTY SPECIFIED HEREIN, THE PRODUCT IS PROVIDED “AS-IS”...

  • Page 49

    Trademarks: D-Link is a registered trademark of D-Link Systems, Inc. Other trademarks or registered trademarks are the property of their respective manufacturers or owners.

  • Page 50

    Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. For detailed warranty outside the United States, please contact corresponding local D-Link office.

  • Page 51: Technical Support

    Technical Support You can find software updates and user documentation on the D- Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link technical support through our website, or by phone.
