Specification
HT-B01
1
Product Spec
Max. Load:50kg
Net Weight:2.7kg
(
)
Top View
(Front View)
2
Parts Name
Please check out all parts.
12 x 1 ½
G
H
(Lateral View)
TV Bracket x1
#
Wood Screw x 6
M4x15 Screw x 6
4 Sleeve x6
Registered design and patent pending All rights reserved
：
UNIT mm
(
)
Back View
Wall Bracket x1
5/16x2
¼
Wall Anchor x4
M4x15 Anti-thief Screw X6
10x56 Plastic Sleeve x6
.
Advertisement
Table of Contents
Related Manuals for HONTECH HT-B01
Summary of Contents for HONTECH HT-B01
- Page 1 Specification HT-B01 Product Spec Max. Load:50kg ： Net Weight:2.7kg UNIT mm Back View Top View (Front View) (Lateral View) Parts Name Please check out all parts. Wall Bracket x1 TV Bracket x1 12 x 1 ½ Wood Screw x 6 5/16x2 ¼...
- Page 2 Installation HT-B01 Step 1 The wall must be at least 5cm thick. For a wooden wall,please choose wood screws 6pcs 12 x 1 ½ For a concrete wall,please choose wall anchors 4pcs mm(C) 5/16 x 2 ¼ Step 2 At the time of installation,make sure that 2 people hold the LCD TV.
