Specification
HT-C02
1
Product Spec
Max. Load:80kg
Net Weight:3kg
2
Parts Name
Please check out all parts.
TV Bracket x2
4
Sleeve x 4
M4x15 Screw x 4
(
)
Top View
(Front View)
Registered design and patent pending All rights reserved
：
UNIT mm
(Lateral View)
Wall Bracket x1
5/16x2
¼
Wall Anchor x4
12 x 1 ½
#
Wood Screw x 8
M6x15 Screw x 4
.
Advertisement
Table of Contents
Related Manuals for HONTECH HT-C02
Summary of Contents for HONTECH HT-C02
- Page 1 Specification HT-C02 Product Spec Max. Load:80kg ： Net Weight:3kg UNIT mm Top View (Front View) (Lateral View) Parts Name Please check out all parts. Wall Bracket x1 TV Bracket x2 5/16x2 ¼ Wall Anchor x4 Sleeve x 4 12 x 1 ½...
- Page 2 Installation HT-C02 Step 1 The wall must be at least 5cm thick. For a wooden wall,please choose wood screws 6pcs mm(D) 12 x 1 ½ For a concrete wall,please choose wall anchors 4pcs mm(C) 5/16 x 2 ¼ E,FG Step 2 At the time of installation,make sure that 2 people hold the LCD TV.
