Specification
HT-A02
1
Product Spec
Max. Load:30kg
Net Weight:2kg
2
Parts Name
Please check out all parts.
TV Bracket x1
F
M4x15 Screw x6
G
M6x15 Screw x6
5/16 x 2¼
H
Wall Bracket x1
C
D
Wall Anchor x
4
E
Registered design and patent pending All rights reserved
：
UNIT mm
10X56Wall Anchor x6
12
#
x1½ Wood Screw x6
4 Sleeve x6
.
Advertisement
Table of Contents
Related Manuals for HONTECH HT-A02
Summary of Contents for HONTECH HT-A02
- Page 1 Specification HT-A02 Product Spec Max. Load:30kg ： Net Weight:2kg UNIT mm Parts Name Please check out all parts. TV Bracket x1 Wall Bracket x1 M4x15 Screw x6 10X56Wall Anchor x6 x1½ Wood Screw x6 M6x15 Screw x6 5/16 x 2¼...
- Page 2 Installation HT-A02 Step 1 The wall must be at least 5cm thick. For a wooden wall,please choose wood screws 6pcs 5.5x38mm(D) For a concrete wall,please choose wall anchors 4pcs 10x56mm(H) Step 2 At the time of installation,make sure that 2 people hold the LCD TV.
