Specification
HT-A06
1
Product Spec
Max. Load:80kg
Net Weight:1.7kg
(
)
Top View
(Front View)
2
Parts Name
Please check out all parts.
M4x12 Screw x6
(Lateral View)
TV Bracket x1
4 Sleeve x6
Registered design and patent pending All rights reserved
：
UNIT mm
(
)
Back View
Wall Bracket x1
10x56 Wall Anchor x4
5.5x38 Wood Screw x6
M6x10 Screw x6
.
Advertisement
Table of Contents
Related Manuals for HONTECH HT-A06
Summary of Contents for HONTECH HT-A06
- Page 1 Specification HT-A06 Product Spec Max. Load:80kg ： Net Weight:1.7kg UNIT mm Top View Back View (Front View) (Lateral View) Parts Name Please check out all parts. Wall Bracket x1 10x56 Wall Anchor x4 TV Bracket x1 5.5x38 Wood Screw x6...
- Page 2 Installation HT-A06 Step 1 The wall must be at least 5cm thick. For a wooden wall,please choose wood screws 6pcs 5.5x38mm(D) For a concrete wall,please choose wall anchors 4pcs 10x56mm(C) Step 2 At the time of installation,make sure that 2 people hold the LCD TV.
