Specification
HT-A05
1
Product Spec
Max. Load:40kg
Net Weight:1.4kg
(
)
Top View
(Front View)
2
Parts Name
Please check out all parts.
TV Bracket x1
Wall Anchor 5/16 x4 & 1/4 4
4 Plastic Sleeve x6
Registered design and patent pending All rights reserved
(
(Lateral View)
Wall Bracket x1
x
：
UNIT mm
)
Back View
4x20 Wood Screw x4
M4x15 Screw x4
.
Advertisement
Table of Contents
Related Manuals for HONTECH HT-A05
Summary of Contents for HONTECH HT-A05
- Page 1 Specification HT-A05 Product Spec Max. Load:40kg ： Net Weight:1.4kg UNIT mm Top View Back View (Front View) (Lateral View) Parts Name Please check out all parts. Wall Bracket x1 TV Bracket x1 Wall Anchor 5/16 x4 & 1/4 4 4x20 Wood Screw x4...
- Page 2 Installation HT-A05 Step 1 The wall must be at least 5cm thick. For a wooden wall,please choose wood screws 6pcs 5x38mm(D) For a concrete wall,please choose wall anchors 4pcs 10x56mm(C) Step 2 At the time of installation,make sure that 2 people hold the LCD TV.
