EN

Remote control

1. – Switch the unit between ON and STANDBY mode.
2. MUTE – Mute or resume the sound.
3. Function buttons – Select the play function.
4. VOL+/VOL- – Increase/decrease the volume level.
5. / – Skip to previous/next track in Bluetooth mode.
6. / PAIR – Play/pause/resume playback in Bluetooth mode.
Press and hold to activate the pairing function in Bluetooth mode or
disconnect the existing paired Bluetooth device.
7. EQ buttons – Select a preset sound mode.

First time installation

Remote control preparation
The provided Remote Control allows the unit to be operated from a
distance.
• Even if the Remote Control is operated within the eff ective range 6m,
remote control operation may be impossible if there are any obstacles
between the unit and the remote control.
• If the Remote Control is operated near other products which generate
infrared rays, or if other remote control devices using infra-red rays are
used near the unit, it may operate incorrectly. Conversely, the other
products may operate incorrectly.
FIRST-TIME USE: The unit has a pre-installed lithium CR2025 battery.
Remove the protective tab to activate the remote control battery.
Remote control battery replacement
2
1
The remote control requires a CR2025, 3V Lithium battery.
1. Push the tab on the side of the battery tray towards the tray.
2. Now slide the battery tray out of the remote control.
3. Remove the old battery. Place a new CR2025 battery into the battery
tray with the correct polarity (+/-) as indicated.
4. Slide the battery tray back into the slot in the remote control.
Placement and Mounting
A
A: Normal Placement (place Soundbar on leveled surface in front of TV)
B: Wall Mounting
Wall Mounting
NOTE:
– Installation must be carried out by qualifi ed personnel only. Incorrect
assembly can result in severe personal injury and property damage (if
you intend to install this product yourself, you must check for installa-
tions such as electrical wiring and plumbing that may be buried inside
the wall). It is the installer's responsibility to verify that the wall will safely
support the total load of the unit and wall brackets.
– Additional tools (not included) are required for the installation.
– Do not overtighten screws.
– Keep this instruction manual for future reference.
– Use an electronic stud fi nder to check the wall type before drilling and
mounting.
1
4
B
764mm
2
3
