Summary of Contents for Trinity TBFPRA-2703
- Page 1 OWNER’S MANUAL TRINITY 4-TIER 15" X 20" X 72" BAMBOO SHELVING - BRONZE ANTHRACITE Model # TBFPRA-2703...
-
Page 3: Parts List
PARTS LIST Your TRINITY 4-Tier 15" x 20" x 72" Bamboo Shelving should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. - Page 4 F (4) B (2) I (1) KEY (I), screw 1 FRAME CONNECTING SCREW (F) into each hole where BOTTOM SIDE FRAME (B) is connected with TOP SIDE FRAME (A). Repeat for remaining FRAME CONNECTING SCREWS (F). © 2018 TRINITY - 800.985.5506...
- Page 5 Do the same for the other 4 ADJUSTABLE SHELF RESTS (G). Place 2 ADJUSTABLE SHELVES (D) on each set of ADJUSTABLE SHELF RESTS (G). Make sure the shelf notches are resting on ADJUSTABLE SHELF RESTS (G). © 2018 TRINITY - 800.985.5506...
- Page 6 TOP SIDE FRAME (A) just below the top FIXED SHELF (C). First, fully secure ANTI-TIPPING KIT (J) to the wall. Next, close cable loop through TOP Wall SIDE FRAME (A) as shown. © 2018 TRINITY - 800.985.5506...
- Page 7 Extra ADJUSTABLE SHELVES (PRA-03-046-1320) and ADJUSTABLE SHELF RESTS (ZBK-01-031-0620) are available for purchase. Please visit our website www.trinityii.com or contact our Customer Service (see last page of the manual) to place your order. PRA-03-046-1320 ADJUSTABLE SHELF (1) ZBK-01-031-0620 ADJUSTABLE SHELF REST (4) © 2018 TRINITY - 800.985.5506...
- Page 8 SERVICE PARTS LIST – TBFPRA-2703 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XSV-02-011-0007 Anti-tipping kit ZBK-01-002-0635 Screw PRA-14-019-2036 Top Side Frame ZBK-01-031-0620 Adjustable Shelf Rest ZBK-01-002-0615 Frame Connecting Screw PRA-03-046-1320 Adjustable Shelf PRA-14-020-2036...
-
Page 9: Care And Maintenance
Bamboo can be maintained with mineral oil for best results. • Avoid harsh, abrasive cleaners, and other corrosive chemicals. • The product is designed for indoor use. Wipe dry and keep out of direct sunlight. © 2018 TRINITY - 800.985.5506... -
Page 10: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY 4-Tier 15" x 20" x 72" Bamboo Shelving. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. -
Page 11: Year Limited Warranty
Product which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity, during the warranty period. All replaced parts and Products become the property of Trinity and must be returned to Trinity. - Page 12 WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com Monday through Friday 5:00 AM –...
