- Page 1 OWNER’S MANUAL TRINITY 4-TIER NSF 36" x 14" x 54" WIRE SHELVING RACK w/LINERS Model # TBFPBR-0943...
-
Page 2: Parts List
Your TRINITY 4-Tier NSF Wire Shelving Rack w/Liners should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. Parts can also be requested online at www.trinityii.com (Help &... - Page 3 SLIP SLEEVES (D). Stand the unit upright. Note • The level side of SHELF (C) is the TOP side (the TRINITY logo on the corner cylinders should be right-side up). • Use a rubber mallet, if needed, to secure SHELF (C).
- Page 4 Note: Use a rubber mallet, if needed, to secure SHELVES (C). STEP 4 Screw TOP POLE (B) into BOTTOM POLE (A). B (4) The tops of these poles are indicated by the BLACK END CAP. Repeat for remaining 3 TOP POLES (B). © 2018 TRINITY - 800.985.5506...
- Page 5 Repeat Step 5 to install other SHELVES (C) as desired. Note: Use a rubber mallet, if needed, to secure SHELVES (C). STEP 6 Feet Levelers are already screwed into BOTTOM POLES (A). Adjust as needed to ensure your shelving rack is level. © 2018 TRINITY - 800.985.5506...
- Page 6 ASSEMBLY INSTRUCTIONS STEP 7 Place each SHELF LINER (E) onto each SHELF (C) as shown. E (4) © 2018 TRINITY - 800.985.5506...
- Page 7 SERVICE PARTS LIST – TBFPBR-0943 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-01-012-2543 Slip Sleeve XBK-98-003-2538 Feet Leveler PBR-04-025-2650 Top Pole XCL-22-002-3614 Shelf Liner ZSV-01-029-2523 Pole Connector XBK-23-004-2517 End Cap PBR-04-027-2650 Bottom Pole...
-
Page 8: Care And Maintenance
Weight capacity per Shelf (evenly distributed) 350 lb 1400 lb Total weight capacity of Shelving Rack (evenly distributed) CARE AND MAINTENANCE • Avoid harsh, abrasive cleaners, and other corrosive chemicals • This item is not certified for outdoor use © 2018 TRINITY - 800.985.5506... -
Page 9: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY 4-Tier NSF Wire Shelving Rack w/ LINERS. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. - Page 10 © 2018 TRINITY - 800.985.5506...
-
Page 11: Year Limited Warranty
Product which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity, during the warranty period. All replaced parts and Products become the property of Trinity and must be returned to Trinity. - Page 12 WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com Monday through Friday 5:00 AM –...
