  • Page 1 SuperStorage SSG-2029P-ACR24H SSG-2029P-ACR24L USER’S MANUAL Revision 1.0a...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 SuperServer SSG-2029P-ACR24H/L. Installation and maintenance should be performed by experienced technicians only. Please refer to the SSG-2029P-ACR24H/L specifications page on our website for updates on supported memory, processors and operating systems (http://www.supermicro.com).

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Server Chassis Features ....................10 Control Panel ........................10 Front Features ........................11 Rear Features ........................12 1.5 Motherboard Layout ......................13 Quick Reference Table ......................14 Chapter 2 Server Installation 2.1 Overview ..........................17 2.2 Preparing for Setup ......................17 Choosing a Setup Location ....................17...
  • Page 5 SSG-2029P-ACR24H/L User's Manual 3.3 Motherboard Components ....................26 Processor and Heatsink Installation ..................26 The Xeon Scalable Processor ..................27 Overview of the Processor Socket Assembly ..............27 Overview of the Processor Heatsink Module (PHM) .............29 Assembling the Processor Package ................30 Assembling the Processor Heatsink Module (PHM) .............31 Connecting an HFI Carrier Card ...................32...
  • Page 6 Preface Chapter 5 Software 5.1 Microsoft Windows OS Installation ..................60 5.2 Driver Installation ........................62 5.3 SuperDoctor 5 ........................63 ® 5.4 IPMI ............................64 Chapter 6 UEFI BIOS 6.1 Introduction .........................65 Starting the Setup Utility ....................65 6.2 Main Setup .........................66 6.3 Advanced Setup Configurations ..................68 6.4 Event Logs .........................95 6.5 IPMI ............................97 6.6 Security Settings ......................100...
  • Page 7 SSG-2029P-ACR24H/L User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Overview

    Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the SSG-2029P-ACR24H/L. The SSG-2029P-ACR24H/L is based on the X11DPH-T motherboard and the SC216BE1C4-R1K23LPB chassis. In addition to the motherboard and chassis, several important parts that are included with the system are listed below.

  • Page 9: System Features

    Chapter 1: Introduction 1.3 System Features The following table provides you with an overview of the main features of the SSG-2029P-ACR24H/L. Please refer to Appendix C for additional specifications. System Features Motherboard X11DPH-T Chassis SC216BE1C4-R1K23LPB Dual Intel Xeon 81xx/61xx/51xx/41xx/31xx series or 82xx/62xx/52xx/42xx/32xx series processors*...

  • Page 10: Server Chassis Features

    SSG-2029P-ACR24H/L User's Manual 1.4 Server Chassis Features Control Panel The switches and LEDs located on the control panel are described below. See Chapter 4 for details on the control panel connections. Figure 1-1. Control Panel View Control Panel Features Item...

  • Page 11: Front Features

    Chapter 1: Introduction Information LED Status Description Continuously on and red An overheat condition has occurred. (This may be caused by cable congestion.) Blinking red (1 Hz) Fan failure: check for an inoperative fan. Blinking red (0.25 Hz) Power failure: check for an inoperative power supply. Local UID has been activated.

  • Page 12: Rear Features

    SSG-2029P-ACR24H/L User's Manual Rear Features The illustration below shows the features included on the rear of the chassis. Figure 1-3. Chassis Rear View Rear Chassis Features Item Feature Description Power Supply Module 1200W power supply (redundant, with two power modules) 2.5"...

  • Page 13: Motherboard Layout

    Chapter 1: Introduction 1.5 Motherboard Layout Below is a layout of the X11DPH-T with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4. USB2/3 (3.0) SLOT7 JSDCARD1...

  • Page 14: Quick Reference Table

    SSG-2029P-ACR24H/L User's Manual Quick Reference Table Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) JPG1 VGA Enable Pins 1-2 (Enabled) JPL1 LAN1/LAN2 Enable Pins 1-2 (Enabled) JPME1 ME Recovery Pins 1-2 (Normal) JPME2 ME Manufacturing Mode Pins 1-2 (Normal)
  • Page 15 Description (CPU2) SLOT2, SLOT4, PCI-Express 3.0 x16 slot supported by CPU2 SLOT5 S-SATA0, S-SATA1 Powered SATA 3.0 ports with support of Supermicro SuperDOM (Disk-On-Module) T-SGPIO1 Serial Link General Purpose I/O (SGPIO) port USB0/1, USB2/3 Universal Serial Bus (USB) 3.0 ports USB4/5 Internal USB 3.0 header for front access...
  • Page 16 SSG-2029P-ACR24H/L User's Manual #F-0 VCCP1 12v VCCP0 12v #M-0 #E-0 #L-0 VR13 VR13 #D-1 #K-1 5+1 PHASE 6+1 PHASE #D-0 #K-0 up to 255W #C-0 10.4/11.2G #J-0 #B-0 VCCP1 #H-0 VCCP0 #A-1 #G-1 #A-0 #G-0 SNB CORE SNB CORE DDR4...

  • Page 17: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.

  • Page 18: Server Precautions

    SSG-2029P-ACR24H/L User's Manual • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together. • Always make sure the rack is stable before extending a server or other component from the rack.

  • Page 19: Circuit Overloading

    Chapter 2: Server Installation Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

  • Page 20: Installing The Rails

    SSG-2029P-ACR24H/L User's Manual 2.3 Installing the Rails There are a variety of rack units on the market, which may require a slightly different assembly procedure. The following is a basic guideline for installing the system into a rack with the rack mounting hardware provided.

  • Page 21: Releasing The Inner Rail

    Chapter 2: Server Installation Releasing the Inner Rail Releasing Inner Rail from the Outer Rails 1. Identify the left and right outer rail assemblies as described on the previous page. 2. Pull the inner rail out of the outer rail until it is fully extended as illustrated below. 3.

  • Page 22: Installing The Outer Rails On The Rack

    SSG-2029P-ACR24H/L User's Manual Installing the Outer Rails on the Rack Installing the Outer Rails 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3. Hang the hooks of the front of the outer rail onto the slots on the front of the rack. If necessary, use screws to secure the outer rails to the rack, as illustrated above.

  • Page 23: Standard Chassis Installation

    Chapter 2: Server Installation Standard Chassis Installation Installing the Chassis into a Rack 1. Confirm that the inner rails are properly installed on the chassis. 2. Confirm that the outer rails are correctly installed on the rack. 3. Pull the middle rail out from the front of the outer rail and make sure that the ball- bearing shuttle is at the front locking position of the middle rail.
  • Page 24 SSG-2029P-ACR24H/L User's Manual Ball-Bearing Shuttle Figure 2-5. Installing the Server into a Rack Note: Figure is for illustrative purposes only. Always install servers to the bottom of a rack first.

  • Page 25: Chapter 3 Maintenance And Component Installation

    SSG-2029P-ACR24H/L User's Manual Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 26: Motherboard Components

    When receiving a motherboard without a processor pre-installed, make sure that the plastic CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro website for updates on CPU support.

  • Page 27: The Xeon Scalable Processor

    SSG-2029P-ACR24H/L User's Manual The Xeon Scalable Processor Figure 3-2. Xeon Scalable Processors Note: All graphics, drawings, and pictures shown in this manual are for illustration only. The components that came with your server may or may not look exactly the same as those shown in this manual.
  • Page 28 Chapter 3: Maintenance and Component Installation 3. Dust Cover 4. CPU Socket Note: Be sure to cover the CPU socket with the dust cover when the CPU is not installed.

  • Page 29: Overview Of The Processor Heatsink Module (Phm)

    SSG-2029P-ACR24H/L User's Manual Overview of the Processor Heatsink Module (PHM) The Processor Heatsink Module (PHM) contains 1) a heatsink, 2) a narrow processor clip, and 3) the processor. 1. Heatsink 2. Narrow processor clip 3. SKX(-F) Processor (Bottom View for a non-F Model)

  • Page 30: Assembling The Processor Package

    Chapter 3: Maintenance and Component Installation Assembling the Processor Package Attach the processor to the narrow processor clip to create the processor package. Caution: Exercise extreme caution when handling the CPU. Do not touch the underside of the CPU to avoid damaging it. Be sure to wear ESD gloves when handling components. 1.

  • Page 31: Assembling The Processor Heatsink Module (Phm)

    SSG-2029P-ACR24H/L User's Manual Assembling the Processor Heatsink Module (PHM) After creating the processor package assembly, mount it onto the heatsink to create the processor heatsink module (PHM). 1. Locate "1" on the heatsink label and the corner next to it. With your index finger pressing against the screw at this corner, carefully turn the heatsink upside down with the thermal grease side facing up.

  • Page 32: Connecting An Hfi Carrier Card

    F model processor. Two HFI headers are located on the X11DPH-T motherboard. JHFI1 is used for CPU 1, and JHFI2 is for CPU2. (For more information on the JHFI1/JHFI2 headers, see Chapter 4.) Note: The SSG-2029P-ACR24H/L server supports only one F model processor, and thus only one HFI connection.

  • Page 33: Removing The Processor Heatsink Module From The Motherboard

    SSG-2029P-ACR24H/L User's Manual Removing the Processor Heatsink Module from the Motherboard Before removing the processor heatsink module (PHM), power down as described in Section 3.1. 1. Using a T30 Torx-bit screwdriver, turn the screws on the PHM counterclockwise to loosen them from the socket, starting with screw marked #4, in the sequence of 4, 3, 2, 2.

  • Page 34: Memory Installation

    DIMMs or slots. Warning: In dual-CPU configurations, memory must be installed in the DIMM slots associated with the installed CPUs. Note: Visit the product page on the Supermicro website for possible updates to memory support (www.supermicro.com).
  • Page 35 2666 DRx4 16 GB 32 GB 2666 QRX4 2H-64GB 2666 RDIMM 3Ds 8RX4 4H-128GB 2666 LRDIMM QRx4 32 GB 64 GB 2666 QRX4 2H-64GB 2666 LRDIMM 8Rx4 4H-128 GB 2666 Check the Supermicro website for possible updates to memory support.

  • Page 36: Ddr4 Memory Support For The 81Xx/61Xx/51Xx/41Xx/31Xx Platform

    Chapter 3: Maintenance and Component Installation DDR4 Memory Support for the 81xx/61xx/51xx/41xx/31xx Platform Memory Population for X11 DP Motherboard, 16 DIMM Slots With 1 CPU Memory Population Sequence 1 CPU & 1 DIMM CPU1: P1-DIMMA1 1 CPU & 2 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1 1 CPU &...

  • Page 37: Ddr4 Memory Support For The 82Xx/62Xx/52Xx/42Xx/32Xx Platform

    SSG-2029P-ACR24H/L User's Manual DDR4 Memory Support for the 82xx/62xx/52xx/42xx/32xx Platform Symmetric Population within 1 CPU Socket Mode P1-DIMMF1 P1-DIMME1 P1-DIMMD1 P1-DIMMD2 P1-DIMMA2 P1-DIMMA1 P1-DIMMB1 P1-DIMMC1 Channel Config. DRAM1 DRAM1 DRAM1 DCPMM DCPMM DRAM1 DRAM1 DRAM1 2-1-1 DRAM2 DRAM2 DRAM2 DCPMM...

  • Page 38: Dimm Population Requirements For Cpus

    Chapter 3: Maintenance and Component Installation DIMM Population Requirements for CPUs For optimal memory performance, follow the tables below when populating memory modules. Key Parameters for DIMM Configurations Parameters Possible Values Number of Channels 1, 2, 3, 4, 5, or 6 Number of DIMMs per Channel 1DPC (1 DIMM Per Channel) or 2DPC (2 DIMMs Per Channel) DIMM Type...

  • Page 39: Pci Expansion Card Installation

    SSG-2029P-ACR24H/L User's Manual PCI Expansion Card Installation The SSG-2029P-ACR24H can accommodate up to seven low-profile add-on cards in the PCI expansion slots on the serverboard. Installing Add-on Card 1. Begin by removing the shield for the PCI slot you wish to populate. Make sure that the card you are installing is supported by the slot (see table below).

  • Page 40: Chassis Components

    Chapter 3: Maintenance and Component Installation 3.4 Chassis Components Hard Drives Up to 24 hot-swap 2.5" hard drives are supported by the chassis. You do not need to access the inside of the chassis or remove power to replace or swap hard drives The hard drives are mounted in drive carriers to simplify their installation and removal from the chassis.

  • Page 41: Hard Drive Carrier Indicators

    Figure 3-5. Mounting a Drive in a Carrier Figure 3-6. Installing a Drive Carrier into its Bay Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at http://www.

  • Page 42: System Fans

    Figure 3-7. Drive Bays: Logical Configuration System Fans Three 8-cm hot-swap chassis fans provide the cooling for the SSG-2029P-ACR24H/L. It is very important that the top cover of the chassis is properly installed in order for the cooling air to circulate properly through the chassis and cool the components.

  • Page 43: Air Shrouds

    SSG-2029P-ACR24H/L User's Manual Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. The SSG-2029P-ACR24H/L air shrouds do not require screws for installation. Installing the Main Air Shroud Begin by removing power from the system as described in Section 3.1.

  • Page 44: Power Supply

    Chapter 3: Maintenance and Component Installation Power Supply The SSG-2029P-ACR24H/L has two redundant, hot-plug 1200 Watt power supplies. The power modules are hot-swappable, enabling them to be replaced without powering down the system. These power supplies are auto-switching capable, allowing them to automatically sense and operate at a 100v to 240v input voltage.

  • Page 45: Attaching A Jbod Expansion Chassis

    Figure 3-9. Replacing a Power Supply Module 3.5 Attaching a JBOD Expansion Chassis The SSG-2029P-ACR24H/L features dual JBOD expansion ports. The JBOD attachment will vary depending on the specific JBOD chassis that is being connected. A two-cable attachment (x8 SAS lanes) is recommended...

  • Page 46: Chapter 4 Motherboard Connections

    SSG-2029P-ACR24H/L User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A serverboard layout indicating component locations may be found in Chapter 1.

  • Page 47: Headers And Connectors

    Chapter 4: Motherboard Connections Processor Power Connector JPWR1, JPWR2 and JPWR4 are the 8-pin 12V DC power input for the CPU or alternative single power source for a special enclosure when the 24-pin ATX power is not in use. 12V 8-pin Power Pin Definitions Pin# Definition...
  • Page 48 4-7 ports are supported by the Intel PCH, while S-SATA0/1 are supported by Intel SCU. S-SATA1/2 can be used with Supermicro SuperDOMs, which are yellow SATA DOM connectors with built-in power pins that do not require external power cables. Supermicro SuperDOMs are backward-compatible with regular SATA HDDs or SATA DOMs that need external power cables.
  • Page 49 Chapter 4: Motherboard Connections TPM Header The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is available from a third-party vendor. A TPM/Port 80 connector is a security device that supports encryption and authentication in hard drives. It allows the motherboard to deny access if the TPM associated with the hard drive is not installed in the system.

  • Page 50: Control Panel

    SSG-2029P-ACR24H/L User's Manual PCI-E M.2 Slots This motherboard has two PCI-E M.2 slots (M.2-C1/M.2-C2). The M.2, formerly known as "Next Generation Form Factor (NGFF)" replaces a mini PCI-E slot. M.2 allows for a variety of card sizes and offers increased functionality and spatial efficiency. The M.2 socket on the motherboard supports PCI-E 3.0 X4 (32 Gb/s) SSD cards in the 2260, 2280 and 22110 form...
  • Page 51 Chapter 4: Motherboard Connections Power Button The Power Button connection is located on pins 1 and 2 of JF1. Momentarily contacting both pins will power on/off the system. This button can also be configured to function as a suspend button (with a setting in the BIOS - see Chapter 7). To turn off the power when the system is in suspend mode, press the button for 4 seconds or longer.
  • Page 52 SSG-2029P-ACR24H/L User's Manual NIC1/NIC2 (LAN1/LAN2) The NIC (Network Interface Controller) LED connection for LAN port 1 is located on pins 11 and 12 of JF1, and LAN port 2 is on pins 9 and 10. Attach the NIC LED cables here to display network activity.

  • Page 53: Ports

    Chapter 4: Motherboard Connections 4.3 Ports VGA Port The onboard VGA port is located next to IPMI LAN port on the I/O back panel. Use this connection for VGA display. Serial Port There is one COM port (COM1) on the I/O back panel on the motherboard. The COM port provides serial communications.

  • Page 54: Rear I/O Ports

    SSG-2029P-ACR24H/L User's Manual Rear I/O Ports See the figure below for the locations and descriptions of the various I/O ports on the rear of the motherboard. Figure 4-2. Rear I/O Ports Rear I/O Ports Description Description COM1 USB 3 (USB 3.0) USB 0 (USB 3.0)
  • Page 55 Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com. UID Switch...

  • Page 56: Jumpers

    SSG-2029P-ACR24H/L User's Manual 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 57 Chapter 4: Motherboard Connections VGA Enable/Disable JPG1 allows you to enable or disable the VGA port using the onboard graphics controller. The default setting is Enabled. VGA Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled Pins 2-3 Disabled LAN1/2 Enable/Disable Change the setting of jumper JPL1 to enable or disable the LAN1 and LAN2 Ethernets ports, respectively.
  • Page 58 SSG-2029P-ACR24H/L User's Manual C Bus for VRM Jumpers JVRM1 and JVRM2 allow the VRM SMB clock and data to access the Baseboard Management Controller (BMC). JVRM1 (VRM SMB Clock to BMC) Jumper Settings Jumper Setting Definition Closed Enable (SMB Clock to BMC)

  • Page 59: Led Indicators

    Chapter 4: Motherboard Connections 4.5 LED Indicators LAN1/2 LEDs The rear Ethernet ports have two LEDs. On each port, one LED indicates activity when flashing while the other LED may be green, amber or off to indicate the speed of the connection. LAN1/2 Link LED LAN1/2 Activity LED LED State...

  • Page 60: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 61 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 62: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash drive or a DVD.

  • Page 63: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 64: Ipmi

    SuperServer SSG-2029P-ACR24H/L User's Manual 5.4 IPMI The X11DPH-T supports the Intelligent Platform Management Interface (IPMI). IPMI is used to provide remote access, monitoring and management. There are several BIOS settings that are related to IPMI. For general documentation and information on IPMI, please visit our website at:...

  • Page 65: Chapter 6 Uefi Bios

    Chapter 6: UEFI BIOS Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the X11DPH-T motherboard. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 66: Main Setup

    SSG-2029P-ACR24H/L User's Manual 6.2 Main Setup When you first enter the AMI BIOS setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab on the top of the screen. The Main BIOS setup screen is shown below.
  • Page 67 Chapter 6: UEFI BIOS Memory Information Total Memory This item displays the total size of memory available in the system.

  • Page 68: Advanced Setup Configurations

    SSG-2029P-ACR24H/L User's Manual 6.3 Advanced Setup Configurations Use the arrow keys to select the Advanced submenu and press <Enter> to access the submenu items. Warning: Take Caution when changing the Advanced settings. An incorrect value, an incorrect DRAM frequency, or an incorrect BIOS timing setting may cause the system to malfunction.
  • Page 69 Chapter 6: UEFI BIOS Wait For 'F1' If Error Select Enabled to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled. INT19 Trap Response Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will "capture"...
  • Page 70 SSG-2029P-ACR24H/L User's Manual Power Button Function This feature controls how the system shuts down when the power button is pressed. Select 4 Seconds Override for the user to power off the system after pressing and holding the power button for 4 seconds or longer. Select Instant Off to instantly power off the system as soon as the user presses the power button.
  • Page 71 Chapter 6: UEFI BIOS processor, damaging the system during a virus attack. The options are Enable and Disable. (Refer to Intel and Microsoft websites for more information.) Intel Virtualization Technology Select Enable to use Intel Virtualization Technology which will allow the I/O device assignments to be directly reported to the VMM (Virtual Memory Management) through the DMAR ACPI tables.
  • Page 72 SSG-2029P-ACR24H/L User's Manual will be expanded from 8 bits to 16 bits to provide 512 APIDs to each thread to enhance CPU performance. The options are Disable and Enable. AES-NI Select Enable to use the Intel Advanced Encryption Standard (AES) New Instructions (NI) to ensure data security.
  • Page 73 Chapter 6: UEFI BIOS CPU C6 Report Select Enable to allow the BIOS to report the CPU C6 state (ACPI C3) to the operating system. During the CPU C6 state, power to all caches is turned off. The options are Auto, Enable, and Disable.
  • Page 74 SSG-2029P-ACR24H/L User's Manual • UPI Global MMIO High Base/Limit • UPI PCI-E Configuration Base/Size Degrade Precedence Use this feature to select the degrading precedence option for Ultra Path Interconnect connections. Select Topology Precedent to degrade UPI features if system options are in conflict.
  • Page 75 Chapter 6: UEFI BIOS Directory A to Directory S in the NFS (Network File System) to optimize system performance. The options are Disable, Enable, and Auto. LLC Dead Line Alloc Select Enable to opportunistically fill the deadlines in LLC. The options are Enable, Disable, and Auto.
  • Page 76 SSG-2029P-ACR24H/L User's Manual Page Policy Use this feature to set the page policy for onboard memory support The options are Closed, Adaptive and Auto. IMC Interleaving Use this feature to configure interleaving settings for the IMC (Integrated Memory Controller), which will improve memory performance. The options are 1-way Interleaving, 2-way Interleaving, and Auto.
  • Page 77 Chapter 6: UEFI BIOS Correctable Error Threshold Use this item to enter the threshold value for correctable memory errors. The default setting is 10. SDDC Plus One Select Enable for SDDC (Single Device Data Correction) Plus One support, which will increase the reliability and serviceability of your system memory.
  • Page 78 SSG-2029P-ACR24H/L User's Manual MCP0 (IIO PCIe Br4) This feature configures the PCI-E Bifuraction setting for a PCI-E port specified by the user. The options are x16 and Auto. MCP1 (IIO PCIe Br5) This feature configures the PCI-E Bifuraction setting for a PCI-E port specified by the user.
  • Page 79 Chapter 6: UEFI BIOS Relaxed Ordering Select Enable to enable Relaxed Ordering support which will allow certain transactions to violate the strict-ordering rules of PCI and to be completed prior to other transactions that have already been enqueued. The options are Disable and Enable. Intel VT for Directed I/O (VT-d) ...
  • Page 80 SSG-2029P-ACR24H/L User's Manual Intel VMD Technology  Intel VMD for Volume Management Device on CPU1/CPU2  VMD Configuration for PStack0/VMD Configuration for PStack1/VMD Configuration for PStack2 Intel VMD for Volume Management Device Select Enable to enable Intel Volume Management Device support for the device speci- fied by the user.
  • Page 81 Chapter 6: UEFI BIOS Operational Firmware Version Backup Firmware Version Recovery Firmware Version ME Firmware Status #1/ME Firmware Status #2 Current State Error Code PCH SATA Configuration  When this submenu is selected, the AMI BIOS automatically detects the presence of the SATA devices that are supported by the Intel PCH chip and displays the following items: SATA Controller This item enables or disables the onboard SATA controller supported by the Intel PCH chip.
  • Page 82 SSG-2029P-ACR24H/L User's Manual SATA Port 0 - SATA Port 7 Hot Plug Select Enable to support Hot-plugging for the device installed on a selected SATA port which will allow the user to replace the device installed in the slot without shutting down the system.
  • Page 83 Chapter 6: UEFI BIOS sSATA RAID Option ROM/UEFI Driver (Available when the item "Configure SATA as" is set to "RAID") Select EFI to load the EFI driver for system boot. Select Legacy to load a legacy driver for system boot. The options are Disable, EFI, and Legacy. sSATA Port 0/sSATA Port 1 Hot Plug Select Enable to support Hot-plugging for the device installed on an sSATA port selected by...
  • Page 84 SSG-2029P-ACR24H/L User's Manual PCI PERR/SERR Support Use this feature to enable or disable the runtime event for SERR (System Error)/ PERR (PCI/ PCI-E Parity Error). The options are Enabled and Disbled. Maximum Read Request Select Auto for the system BIOS to automatically set the maximum size for a read request for a PCI-E device to enhance system performance.
  • Page 85 Chapter 6: UEFI BIOS Onboard Video Option ROM Use this feature to select the Onboard Video Option ROM type. The options are Disabled, Legacy and EFI.  Network Stack Configuration Network Stack Select Enabled to enable PXE (Preboot Execution Environment) or UEFI (Unified Extensible Firmware Interface) for network stack support.
  • Page 86 SSG-2029P-ACR24H/L User's Manual  Super IO Configuration Super IO Chip AST2500  Serial Port 1 Configuration Serial Port 1 Select Enabled to enable the onboard serial port specified by the user. The options are Enabled and Disabled. Device Settings This feature displays the base I/O port address and the Interrupt Request address of a serial port specified by the user.
  • Page 87 Chapter 6: UEFI BIOS Serial Port 2 Attribute Select SOL to use COM Port 2 as a Serial_Over_LAN (SOL) port for console redirection. The options are COM and SOL. Serial Port Console Redirection  COM 1 Console Redirection Select Enabled to enable COM Port 1 for Console Redirection, which will allow a client machine to be connected to a host machine at a remote site for networking.
  • Page 88 SSG-2029P-ACR24H/L User's Manual Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None and Hardware RTS/CTS.
  • Page 89 Chapter 6: UEFI BIOS Console Redirection Settings (for SOL/COM2)  Use this feature to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Terminal Type Use this feature to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set.
  • Page 90 SSG-2029P-ACR24H/L User's Manual Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server. The options are Disabled and Enabled. Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Disabled and Enabled.
  • Page 91 Chapter 6: UEFI BIOS EMS Console Redirection Settings Out-of-Band Management Port The feature selects a serial port in a client server to be used by the Windows Emergency Management Services (EMS) to communicate with a remote host server. The options are COM1 (Console Redirection) and COM2/SOL (Console Redirection).
  • Page 92 SSG-2029P-ACR24H/L User's Manual High Precision Timer Select Enabled to activate the High Precision Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in synchronizing multimedia streams, providing smooth playback and reducing the dependency on other timestamp calculation devices, such as an x86 RDTSC Instruction embedded in the CPU.
  • Page 93 Chapter 6: UEFI BIOS • Active PCR Banks • Available PCR Banks Pending Operation Use this feature to schedule a TPM-related operation to be performed by a security (TPM) device at the next system boot to enhance system data integrity. Your system will reboot to carry out a pending TPM operation.
  • Page 94 SSG-2029P-ACR24H/L User's Manual Note 1: If the option for this item (TXT Support) is set to Enabled, be sure to disable EV DFX (Device Function On-Hide) support for the system to work properly. (EV DFX is under "IIO Configuration" in the "Chipset/North Bridge" submenu).

  • Page 95: Event Logs

    Chapter 6: UEFI BIOS 6.4 Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot. The options are Enabled and Disabled. Erasing Settings Erase Event Log Select Enabled to erase all error events in the SMBIOS (System Management BIOS) log...
  • Page 96 SSG-2029P-ACR24H/L User's Manual MECI (Multiple Event Count Increment) Enter the increment value for the multiple event counter. Enter a number between 1 to 255. The default setting is 1. METW (Multiple Event Count Time Window) Use this feature to determine how long (in minutes) the multiple event counter should wait before generating a new event log.

  • Page 97: Ipmi

    Chapter 6: UEFI BIOS 6.5 IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. When you select this submenu and press the <Enter> key, the following information will display: • BMC Firmware Revision: This feature indicates the IPMI firmware revision used in your system.
  • Page 98 SSG-2029P-ACR24H/L User's Manual When SEL is Full This feature allows the user to determine what the BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full.
  • Page 99 Chapter 6: UEFI BIOS The following features will be displayed: • Current Configuration Address Source • Station IPV6 Address • Prefix Length • IPV6 Router1 IP Address • IPV6 Address Status • IPV6 DHCP Algorithm...

  • Page 100: Security Settings

    SSG-2029P-ACR24H/L User's Manual 6.6 Security Settings This menu allows the user to configure the following security settings for the system. Administrator Password Use this feature to set the administrator password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long.
  • Page 101 Chapter 6: UEFI BIOS Secure Boot If this feature is set to Enabled, Secure Boot will be activated when a Platform Key (PK) is entered. A Platform Key is a security key used to manage the security settings of the platform firmware used in your system.
  • Page 102 SSG-2029P-ACR24H/L User's Manual and the key source of the Key-Exchange-Keys. The options are Save to File, Set New, and Erase. Authorized Signatures  This feature allows the user to enter and configure a set of values to be used as Authorized Signatures for the system.

  • Page 103: Boot Settings

    Chapter 6: UEFI BIOS 6.7 Boot Settings Use this feature to configure Boot Settings: Boot Mode Select Use this feature to select the type of devices to be used for system boot. The options are Legacy, UEFI (Unified Extensible Firmware Interface), and Dual. Legacy to EFI Support Select Enabled for the system to boot from an EFI OS when the Legacy OS fails.
  • Page 104 SSG-2029P-ACR24H/L User's Manual Add New Boot Option This feature allows the user to add a new boot option to the boot priority features for your system. Add Boot Option Use this feature to specify the name for the new boot option.
  • Page 105 Chapter 6: UEFI BIOS  Delete Driver Option Use this item to select a boot driver to delete from the boot priority list. Delete Drive Option Select the target boot driver to delete from the boot priority list.  Hard Disk Drive BBS Priorities •...

  • Page 106: Save & Exit

    SSG-2029P-ACR24H/L User's Manual 6.8 Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Save Options Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system configuration and reboot the computer.
  • Page 107 Chapter 6: UEFI BIOS Default Options Restore Optimized Defaults To set this feature, select Restore Defaults from the Exit menu and press <Enter> to load manufacturer default settings which are intended for maximum system performance but not for maximum stability. Save As User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <Enter>.

  • Page 108: Appendix A Bios Codes

    SSG-2029P-ACR24H/L User's Manual Appendix A BIOS Codes A.1 BIOS Error POST (Beep) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 109 When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 110: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 111 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 112 SSG-2029P-ACR24H/L User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬...
  • Page 113 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 114 SSG-2029P-ACR24H/L User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 115 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 116 SSG-2029P-ACR24H/L User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원...
  • Page 117 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 118 SSG-2029P-ACR24H/L User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial,...
  • Page 119 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 120 SSG-2029P-ACR24H/L User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제...
  • Page 121 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 122 SSG-2029P-ACR24H/L User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 123 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 124 SSG-2029P-ACR24H/L User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 125 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 126 SSG-2029P-ACR24H/L User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 127 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 128 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 129 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 130: Appendix C System Specifications

    SSG-2029P-ACR24H/L User's Manual Appendix C System Specifications Processors Dual Intel Xeon 81xx/61xx/51xx/41xx/31xx series or 82xx/62xx/52xx/42xx/32xx series processors in a Socket P type socket Note: Please refer to the motherboard specifications pages on our website for updates to supported processors. Chipset...
  • Page 131 Appendix C: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55032 Class A, EN 61000-3-2/3-3, CISPR 32 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) Other: VCCI-CISPR 32 and AS/NZS CISPR 32 Environmental: Directive 2011/65/EU, Delegated Directive (EU) 2015/863 and Directive 2012/19/EU...

  • Page 132: Appendix D Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 133 USB device or a writable CD/DVD. Note: If you cannot locate the "Super.ROM" file in your driver disk, visit our website www.supermicro.com to download the BIOS image into a USB flash device and rename it to "Super.ROM" for BIOS recovery use.
  • Page 134 SSG-2029P-ACR24H/L User's Manual 4. After locating the new BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
  • Page 135 Appendix D: UEFI BIOS Recovery 6. After the BIOS recovery process is completed, press any key to reboot the system. 7. Using a different system, extract the BIOS package into a USB flash drive. 8. Press <Del> continuously during system boot to enter the BIOS setup utility. From the top of the tool bar, click on Boot and press <Enter>...
  • Page 136 SSG-2029P-ACR24H/L User's Manual 9. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory that contains the BIOS package you extracted earlier from Step 7. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process.

This manual is also suitable for:

Ssg-2029p-acr24l

Table of Contents
