D-Link SECURICAM DCS-7110 Specifications

D-Link SECURICAM DCS-7110 Specifications

Hd outdoor day & night network camera
Hide thumbs Also See for SECURICAM DCS-7110:

Advertisement

Surveillance |
DCS-7110
Product highlights
1/4" Megapixel progressive CMOS sensor
HD resolution: 1280 x 800 (Megapixel) at 30 fps
IP-66 certified weatherproof housing
PoE powered – no need for a separate
power supply
Built-in IR LEDs for Day & Night operation
(15 m. illumination distance)
Built-in IR-Cut Removable (ICR) filter, for
enhanced colour rendering in the day and
good results in low light conditions
Simultaneous streaming in H.264, MJPEG and
MPEG-4 compression
Hardware-based motion detection
Tamper detection
IPv6 support
Privacy mask function
3GPP support – watch live video from a
compatible smartphone
Digital I/O support for sensors and alarms
Open Network Video Interface Forum
(ONVIF) compliant
D-ViewCam (DCS-100) monitoring software
included (support for up to 32 cameras)
HD resolution
High-resolution images ensure that you
capture the details that you need
Reliable 24-Hour Surveillance
Infrared LED Illuminators provide a clear picture
at night for dependable 24-hour surveillance
Outdoor Installation
The IP66 certified enclosure can be mounted
outdoors and operated at temperatures from
-20 to 50 °C
DCS-7110
HD Outdoor Day & Night Network Camera
The D-Link DCS-7110 is a high-definition
outdoor network camera, equipped with a
1/4" Megapixel CMOS sensor and 4 mm F1.5
fixed-focus lens. The DCS-7110 is capable
of capturing video in both dark and light
environments with its built-in IR LEDs and
removable IR-cut filter which provides high
quality video day or night. The ICR Filter
can be manually applied via the web, or set
to automatically adjust based on lightning
conditions. Capture crisp color images during
the daytime and detailed greyscale images
at night or in or low-light conditions.
Multiple Video Streams
The DCS-7110 supports simultaneous
streaming of H.264, MPEG-4, and MJPEG
video to provide both high-quality and
bandwidth-efficient compression formats.
MJPEG delivers excellent file integrity, ideal
for situations which require extensive image
detail. H.264 produces a small file size, making
it more useful for extended recording or for
use in low-bandwidth networks. Additionally,
the DCS-7110 supports multicast H.264
streaming, allowing users to view the camera
images by subscribing to a multicast group
on the network.
Flexible Connectivity
The DCS-7110 includes input and output ports
for connectivity to external devices such as
IR sensors, switches, and alarm relays. It also
comes with an RS-485 interface, providing
connectivity to an optional pan/tilt enclosure.
The DCS-7110 also incorporates Power over
Ethernet (PoE), allowing it to be easily installed
in a variety of locations without the need for
supplemental power cabling.
Tamper Detection
Designed to be mounted outdoors, the
DCS-7110 includes an IP66 certified enclosure
which protects against the environmental
elements. This makes it suitable for
tamperprone locations such as transportation
hubs, schools, or correctional facilities.
The tamper detection feature can sense
whenever the camera has been redirected,
de-focused, blocked, or spray-painted, and
respond promptly with a visible or audible alarm.
Removable IR-Cut filter
The DCS-7110 comes with a ICR Filter which
can be manually applied via a web interface, or
can be set to automatically adjust based on
lighting conditions. This feature allows the
camera to capture crisp colour images during
the daytime, and grayscale images at night.
Open Network Video Interface Forum
(ONVIF) compliant
The Open Network Video Interface Forum
(ONVIF) is standards relating to open IP
video networking. The DCS-7110 is ONVIF
compliant and therefore interoperable
with other manufacturer's products on the
same network such as cameras, storage
systems, video analytics products and Video
Management Systems.
Centralised management with D-ViewCam™
D-ViewCam™ IP camera surveillance software is
a comprehensive surveillance system designed
to centrally manage multiple IP cameras.
Supporting up to 32 IP cameras, D-ViewCam™
is compatible with all current D-Link IP cameras,
Video Servers and offers digital monitoring
and recording capabilities of video, audio, and
events for various security applications. This
software provides users with a wide array of
features for added convenience, including video
recording, playback, video live view, offering
users powerful surveillance software that's easy
to use. D-ViewCam™ software is included free of
charge with DCS-7110.
1

Advertisement

loading

Summary of Contents for D-Link SECURICAM DCS-7110

  • Page 1 Removable IR-Cut filter The DCS-7110 comes with a ICR Filter which can be manually applied via a web interface, or can be set to automatically adjust based on lighting conditions.
  • Page 2: Camera Dimensions

    D-Link Corporation. No. 289 Xinhu 3rd Road, Neihu, Taipei 114, Taiwan. Specifications are subject to change without notice. D-Link is a registered trademark of D-Link Corporation and its overseas subsidiaries. All other trademarks belong to their respective owners. 2010 D-Link Corporation. All rights reserved. Release 01 (November 2010)
