AlleyOOP Sports 12ft VariableBounce Trampoline System User Manual page 18

Assembly and Installation Instructions
Pole 4
Pole 3
Pole 5
(Top view.
Leg assemblies
Pole 6
Pole 2
shown with dotted
lines.)
Start
Pole 1
Pole 7
Place end of net with warning
Pole 8
label here
20)
Become familiar with the numbering of the poles, as shown above. The doorway will be an overlapping section of net between
pole 1 and pole 8, and will be directly over a U-leg. Stretch the net out, and locate the warning label and tag on one end. Put this end
down to the left of pole 1, and lay the rest of the net out counter-clockwise around the circumference of the trampoline, along the out-
side of the enclosure poles. See image above and next photo below.
Pole 8
Pole 8
End of net with tag
and warning placard
Warning Placard
View from outside trampoline showing doorway
21)
The front (outside) of the net has a tag and warning label. Ensure that they are on the bottom of the net, facing out,
and are visible to users as they enter the trampoline. Correct positioning of the warning placard is important for net
placement in the next step.
18
