ZyXEL Communications C2100Z Quick Start Manual

Wifi-n/ac vdsl2 4-port bonding combo wan voip iad
Hide thumbs
Table of Contents

Advertisement

Quick Links

C2100Z
WiFi-N/AC VDSL2 4-port
Bonding Combo WAN VoIP IAD
Version 1.00
Edition 1, 09/2015
Quick Start Guide
Default Login Details
LAN IP Address
User Name
Password
www.zyxel.com
http://192.168.0.1
admin
Check the device label
Copyright © 2015 ZyXEL Communications Corporation

Advertisement

Table of Contents
loading

Related Manuals for ZyXEL Communications C2100Z

Summary of Contents for ZyXEL Communications C2100Z

  • Page 1 C2100Z WiFi-N/AC VDSL2 4-port Bonding Combo WAN VoIP IAD Version 1.00 Edition 1, 09/2015 Quick Start Guide Default Login Details LAN IP Address http://192.168.0.1 User Name admin Password Check the device label www.zyxel.com Copyright © 2015 ZyXEL Communications Corporation...
  • Page 2 Device Panels POWER RESET POWER USB SLOT WAN/LAN PORT INTERNET WAN/LAN ETHERNET PORTS 1-4 ETHERNET HPNA HPNA PORT WI-FI 2.4G VOIP PORT WI-FI 5G VOIP DSL PORT BUTTON...
  • Page 3 Overview The Device is a VDSL2 bonding integrated access device (IAD) with a four-port built-in Ethernet switch and IEEE 802.11ac wireless. The Device allows wired and wireless clients to safely access the Internet. Two lines of telephony service are provided with VoIP technology for making calls over the Internet.

  • Page 4: Hardware Setup

    Hardware Setup To connect your Device: 1. Use a telephone cable to connect your Device’s DSL port to a telephone jack (or the DSL or modem jack on a splitter if you have one). 2. ETHERNET: Use an Ethernet cable to connect a computer to a LAN port for initial configuration and/or Internet access.
  • Page 5 4. VOIP: Use a telephone cable (and any telephone adaptor provided with your C2100Z) to connect a telephone to the VoIP 1 or VoIP 2 port. If you only have one telephone, you should use port 1.

  • Page 6: Internet Connection Setup

    • The WPS light is green when WPS is enabled and blinks amber while WPS is in process. • The VOIP lights stay on when your SIP account is registered and they blink if the receiver is off the hook. •...
  • Page 7 Manual Connection You can also manually log into the Device’s Web Configurator and configure the Internet connection. 1. In your browser, if the Device does not automatically re-direct you to the login screen, go to http://192.168.0.1. 2. Enter the default user name admin and password (see the Device’s label).
  • Page 8 3. The main screen appears. Click Quick Setup to configure the Device’s Internet access. 4. Enter the user name and password provided by your ISP. Click Apply to finish the configuration. 5. The DSL lights are green on your Device and the INTERNET light comes on when the Internet is ready for you to use.

  • Page 9: Set Up A Wireless Network

    Set Up a Wireless Network You can set up a wireless network using the following methods: Using Wireless Protected Setup (WPS) Press the WPS button on the Device’s front panel for more than 5 seconds to turn the WPS function on. Follow these steps to add a WPS-enabled device to the wireless network using the WPS button.
  • Page 10 Set Up a Wireless Network Manually The wireless LAN on your Device is enabled by default. To add a wireless client to the network, use the settings found on the bottom panel of your Device. Configure wireless devices that you want to connect to the wireless network to use the same wireless settings as the Device.

  • Page 11: Wall Mounting

    Wall Mounting The following are dimensions of a screw anchor and M4 tap screw used for wall mounting. All measurements are in millimeters (mm). 1. Locate a high position on a wall that is free of obstructions. Use a sturdy wall. 2.
  • Page 12 3. Drill the two screw holes in the wall. Make sure the distance between the centers of the holes is the same as the wall-mount holes. Be careful to avoid damaging pipes or cables located inside the wall when drilling holes for the screws. 4.
  • Page 13 5. Insert and slowly screw the screws into the anchors (or the holes if you are not using anchors). Make sure the screws are snugly fastened to the wall. They need to hold the weight of the Device with the connection cables. Do not screw the screws all the way into the wall.

  • Page 14: Federal Communications Commission (Fcc)

    Federal Communications Commission (FCC): This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 15 This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs. COMPANY: ZyXEL Communications Inc. ADDRESS: 1130 N. Miller St., Anaheim CA, 92806 USA TEL NO.: 714-6320882...

  • Page 16: Safety Warnings

    Safety Warnings • Do NOT use this product near water, for example, in a wet basement or near a swimming pool. • Do NOT expose your device to dampness, dust or corrosive liquids. • Do NOT store things on the device. •...
  • Page 17 • This reminder is provided to call the CATV systems installer’s attention to Section 820-93 of the National Electric Code which provides guidelines for grounding and, in particular, specifies that the Coaxial cable shield shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
