Winix 5300-2 User Manual page 15

FILTER CARE
4. Replacing Filters
① Insert the True HEPA filter first, then the Carbon filter.
② Insert the Pre-filter.
•Insert bottom tabs of the Pre-filter into the slots on either side of the lower
part of the unit, then rotate upward to insert the upper tabs into the slots at the
top part of the unit until sides audibly click into place.
Replace the front panel by first inserting the latch at the bottom
③
edge into the base of the unit, then rotate the panel upward toward
the top of the unit until the magnets pull the lid closed.
5. Resetting The Unit
After replacing the filters, turn the
①
power onto the unit and then use
a thin object, such as a paper clip,
to press the RESET switch for 5
seconds.
English
True
HEPA
filter
▶
Carbon
filter
Tabs
Latch
▶
Pre-filter
15
5300-2
