Getting to Know the Radio
Radio Overview
1.
Antenna
2.
FlashlightCall Button
3.
MONI Button (Monitor)
4.
PTT Button (Push-To-Talk)
5.
VFO / MR Button
(Frequency Mode/ Channel Mode)
6.
LED Indicator
7.
Strap Buckle
http://www.baofengradio.us
8.
Accessory Jack
9.
A / B Button
(Frequency Display Switch)
10.
Band Button (Not Present on Recent Models)
11.
Numeric Keypad
12.
Speaker & Microphone
13.
Battery Pack
14.
Battery Contacts
15.
Battery Remove Button
http://baofengradio.us
14
