Charging and Battery Maintenance

Charging the Battery
Follow the steps below to set up and use the charger:
1. Plug the end of the power adapter into the charger base.
2. Plug the power adapter into an electrical wall socket.
3. Place the radio or battery in the charging slot on the charger.
4. Make sure the contact plates of the battery are making contact with the charger. Ensure that the radio fits snugly into
the dock. When the red LED stays on, the radio is charging.
5. The radio is fully charged once the LED on the charger stays green. Please remove the radio after it is fully charged to
avoid over-charging the battery.
http://www.baofengradio.us
Charging Status
Standby (no-load)
Charging
Fully Charged
Error
http://baofengradio.us
Charger LED Codes
LED Indication
Red LED flashes while Green LED glows
Red LED glows solidly
Green LED glows solidly
Red LED flashes while Green LED glows
