- Page 1 Air Conditioner Service Manual http://splitoff.ru/tehn-doc.html...
- Page 2 MODEL: AC-S7CG Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html...
-
Page 3: Table Of Contents
CONTENTS TECHNICAL SPECIFICATION......................4 PERFORMANCE CURVE ........................5 EXPLODED VIEW & PARTLIST......................8 CIRCUIT DIAGRAM ..........................12 PCB FUNCTION MANUAL......................... 13 Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html... -
Page 4: Technical Specification
Packing Dimension W x H x D (mm) indoor 870 x 336 x 280 Packing Dimensions W x H x D (mm) outdoor 765 x 500 x 350 Indoor Weight (net /Gross) kg 8/11 Outdoor Weight (Net /Gross) kg 25/29 Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html... -
Page 5: Performance Curve
The change relation between low pressure, operation current and temp. Cooling operation condition: In testing, indoor and outdoor have same work condition. Heating operation Indoor work condition: dry bulb temp.21, wet bulb temp. 15.5 Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html... - Page 6 Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html...
- Page 7 Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html...
-
Page 8: Exploded View & Partlist
EXPLODED VIEW & PART LIST INDOOR UNIT Model No.: AC-S7CG Version: 1.0... - Page 9 33 LED holder 34 Receiver board JD 35 Receiver board K 36 Terminal board T240A 37 Electric box cover 38 Electric box 39 Transformer SC23B 40 Connecting cable 41 Power cord 42 Signal control wire Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html...
- Page 10 OUTDOOR UNIT Model No.: AC-S7CG Version: 1.0...
- Page 11 16 Wiring clamp plate 17 Wiring clamp cover 18 Terminal board T386A 19 Electric plate 20 Comp capacitor 21 Capacitor clamp 22 Fan capacitor 23 Isolation sheet assy 24 Condenser assy 25 Rear grill Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html...
-
Page 12: Circuit Diagram
CIRCUIT DIAGRAM These circuit diagrams are subject to change without notice. Please refer to the ones stuck on the machines. Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html... -
Page 13: Pcb Function Manual
3 minutes passed and it detect the current no more than 13 A, it will back to original state. If it detects overloading states for 6 consecutive times, the machine stops, and must be restarted by remote controller. Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html... - Page 14 If it detects overloading state for 3 consecutive times within 30 minutes, the machine stops, and it must be restarted by remote controller. Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html...
- Page 15 In swing state, the louver swings between position L and position D. d. When the machine is switched off, it is back to position O. When the machine is running and the swing is off, the louver stops at position E. Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html...
- Page 16 1 hour, another 1 will be added. In heating mode, 1 hour after you preset the sleep timer, T set will lower 1 C automatically, another 1 hour, another 1 C will be lowered. Model No.: AC-S7CG Version: 1.0 : http://splitoff.ru/tehn-doc.html...
- Page 17 http://splitoff.ru/tehn-doc.html...
