Summary of Contents for akira AC-S13CG series

  • Page 2 Model: AC-S13CG x 2 Model No: AC-S13CGx2.doc Version 1.0...

  • Page 3: Table Of Contents

    Content Technical specification………………..………………………………………… 4 Performance curve……………………………………………………………….5 Outline & dimension of indoor unit……………………………………………..10 Outline & dimension of outdoor unit…………………………………………… 11 Exploded view of indoor unit ……………………………………………………12 Spare parts list of indoor unit……………………………………………………13 Exploded view of outdoor unit………………………………………………….. 14 Spare parts list of outdoor unit…………………………………………………. 15 Circuit Diagram …………………………………………………………………..16 PCB Function Manual……………………………………………………………17 TECHNICAL SPECIFICATION...

  • Page 4: Performance Curve

    Function Cooling Power supply 1Ph 220~230V-50Hz Capacity (BTU/h) 12000 Rated input (W) 1195 Rated current (A) 5.33 Air flow (m Dehumidifying volume (L/h) EER(W/W) Motor fan speed(r/min) 1190/1090/990 Output power(w) Fan type/piece Cross flow fan-1 Diameter-length(mm) 97mm x 583 Evaporator Aluminum fin-copper tube Row-fin distance(mm) 2-1.4...
  • Page 5 Cooling operation condition: In testing, indoor and outdoor have same work condition. Heating operation Indoor work condition: dry bulb temp.21 , wet bulb temp. 15.5 Model No: AC-S13CGx2.doc Version 1.0...
  • Page 6 Model No: AC-S13CGx2.doc Version 1.0...
  • Page 7 Model No: AC-S13CGx2.doc Version 1.0...
  • Page 8 Model No: AC-S13CGx2.doc Version 1.0...

  • Page 9: Outline & Dimension Of Indoor Unit

    Model No: AC-S13CGx2.doc Version 1.0...

  • Page 10: Outline & Dimension Of Outdoor Unit

    OUTLINES AND DIMENSIONS OF INDOOR UNIT Model No: AC-S13CGx2.doc Version 1.0...

  • Page 11: Exploded View Of Indoor Unit

    OUTLINES AND DIMENSIONS OF OUTDOOR UNIT EXPLODED VIEW OF INDOOR UNIT Model No: AC-S13CGx2.doc Version 1.0...

  • Page 12: Spare Parts List Of Indoor Unit

    Model No: AC-S13CGx2.doc Version 1.0...

  • Page 13: Exploded View Of Outdoor Unit

    PARTS LIST OF INDOOR UNIT Description Part No Wall-Mounting Frame 01252438 Rear Case 22202001 Cross Flow Fan 10352001 Fan Bearing 76512210 Ring of Bearing 76512203 Water Tray Assy 20182012 Swing Louver 10512002 Connecting Lever 1 10582002 Connecting Lever 2 10582003 Manual Lever 10582001 Drainage Pipe...

  • Page 14: Spare Parts List Of Outdoor Unit

    PARTS LIST OF OUTDOOR UNIT Model No: AC-S13CGx2.doc Version 1.0...

  • Page 15: Circuit Diagram

    Description Part No Front Grill 22413431 Nut M6 70310132 Washer 6 70410252 Axial Flow Fan 10333412 Front Plate 01533428 Metal Base 01203030 4-way Valve Capillary Assy 03003030 Compressor RH207VHKC 00120082 Nut with Washer M8 70310014 Handle 26233431 Valve 1/2" 07100147 Valve 1/4"...

  • Page 16: Pcb Function Manual

    PCB FUNCTION MANUAL 3 In 1 PCB Function manual A. Running mode Model No: AC-S13CGx2.doc Version 1.0...
  • Page 17 1. Cooling 2. Dehumidifying 3. Heating 4. Auto B. Input parameters 1. Indoor ambient temp. T in 2. Evaporator tube temp. T eva 3. Setting temp. T set 4. Condenser tube temp. T con C. Targets 1. Indoor motor (motor) 2.
  • Page 18 b. If T set – 2 C < or = T in < or = T set + 2 C ,it goes into dehumidifying running ,the indoor motor run at the low speed, 6 minutes later the compressor stops, another 15 seconds later the outdoor fan stops and another 30 seconds later, the indoor motor stops, 3 and a half minutes later, compressor and outdoor fan run again, indoor motor runs at the low speed, then the machine cycle the above procedures repeatedly.
  • Page 19 secutive times within 30 minutes, the machine stops, and it must be restarted by remote controller. Defrosting conditions and procedures In heating mode, if compressor has run 44 minutes ( in its first 6 minutes it will not detect defrosting temp.) , and it has detected T con < or = -4 C for continuous 1 minutes, it begins to defrost, electric heater will stop for 10 seconds ( even if electric heater is not working), then indoor motor stops, reversing valve becomes...
  • Page 20 Beeper a. When PCB becomes active or receives the signal from the remote controller, the beeper will beep. Indication lamps a. It flashes when defrosting begin. Press the AUTO button a time, the machine runs in AUTO mode, indoor motor runs in low speed, fresh air function is not active, press again the machine stops.
