Summary of Contents for cassini CS-102
- Page 2 INTRODUCTION THIS TELESCOPE HAS BEEN PRODUCED TO PRECISE SPECIFICATIONS. PRIOR TO USING YOUR NEW CASSINI TELESCOPE, PLEASE READ THE FOLLOWING SETUP AND USAGE INSTRUCTIONS. IT IS IMPORTANT TO PROPERLY ASSEMBLE YOUR TELESCOPE IN ORDER TO ALLOW IT TO FUNCTION PROPERLY.
- Page 3 TO CONVERT THE UPSIDE DOWN, IMAGE TO RIGHT SIDE UP. HELICAL RACK & PINION FOCUSING. ALLOWS FOR PRECISE FOCUSING. TWO COUNTER BALANCE WEIGHT ASSEMBLY. CASSINI PLANETARIUM CD-ROM FROM ANY LOCATION YOU CAN SEE THE SKY AT IT APPEARS AT ANY TIME OF DAY, OR EVEN IN THE FUTURE,...
- Page 4 CS-102 TELESCOPE ASSEMBLY INSTRUCTIONS CAUTION: VIEWING THE SUN WITH THIS TELESCOPE OR EVEN THE UNAIDED EYE CAN RESULT IN BLINDNESS OR OTHER SERIOUS EYE DAMAGE WHICH MAY BE PERMANENT. NEVER POINT YOUR TELE- SCOPE AT THE SUN REMOVE ALL PARTS FROM BOX AND IDENTIFY THEM.
- Page 5 BALANCE MARK BALANCE THE MAIN TUBE BY MOVING IT AS SHOWN 7. BALANCE TELESCOPE BY MOVING THE COUNTER WEIGHTS AS SHOWN 8. ATTACH THE SLOW-MOTION KNOB TO THE SHAFT OF SLOW-MOTION ON THE TRIPOD AS SHOWN 9. REMOVE CAPS WHEN TELESCOPE IS IN USE, AND REPLACE WHEN NOT IN USE.
- Page 6 TO SKY MARS-EYE FINDER FRONT CRADLE LOCKING KNOBS HELICAL RACK & PINION FOCUSING ALTITUDE SLOW-MOTION TENSION KNOB AZIMUTH SLOW-MOTION BACK COUNTER BALANCE WEIGHT ASSY COUNTERWEIGHT SHAFT MOUNTING HOLE TRIPOD EYEPIECES ACCESSORY TRAY CASSINI CASSINI 20MM 1.5X ERECTING LENS TRIPOD LOCKING KNOB...
- Page 7 HOW TO USE EYEPIECES & ACCESSORIES PROPER PLACEMENT OF THE EYEPIECES AND ACCESSORIES ARE IMPORTANT IN ORDER TO ASSURE EASY OPERATIONS AND CLEAR VIEWING. PLEASE CONSIDER USING YOUR ACCESSORIES IN THE FOLLOWING ORDER. BY DOING THIS YOU WILL BETTER UNDERSTAND THE IMPACT EACH INDIVIDUAL ACCESSORY HAS ON THE FUNCTION OF YOUR TELESCOPE.
- Page 8 MARS-EYE ELECTRONIC FINDER MOUNTING & ALIGNMENT TO MOUNT: 1) REMOVE MARS-EYE ELECTRONIC FINDER FROM BOX. 2) LOOSEN THUMB SCREWS ON SIDE OF FINDER AND SLIDE FINDER ONTO DOVETAIL MOUNT LOCATED AT TOP OF MAIN TELESCOPE TUBE. 3) TIGHTEN THUMB SCREWS. TO CHECK ALIGNMENT WITH MAIN TELESCOPE:(IMPORTANT!) 1) THE MARS-EYE ELECTRONIC FINDER IS NOT PRE-SET AT FACTORY.
- Page 9 GETTING THE MOST FROM YOUR TELESCOPE TAKE THE TIME TO BECOME FAMILIAR WITH YOUR NEW TELESCOPE. LEARN THE NAMES OF THE VARIOUS PARTS, WHERE THEY ARE LOCATED AND THEIR FUNCTION. IT IS BEST TO PERFORM THESE FUNCTIONS DURING THE DAY TIME. WHEN SETTING UP FOR A VIEWING SESSION, PLACE THE TELESCOPE IN AN AREA SHELTERED FROM THE WIND IF POSSIBLE.
- Page 10 . The customer shall be responsible for all costs of transportation and insurance, both to and from CASSINI/COSMO BRANDS INC., and shall be required to prepay such costs. No expenses, warranties and implied warranties, whether or not...
