Crown IQ-PIP-USP2 CN Reference Manual

Ultra series iq system programmable input processor with cobranet and dsp for crown pip2-compatible amplifiers
Hide thumbs Also See for IQ-PIP-USP2 CN:

Advertisement

Quick Links

Download this manual See also: Installation Manual
-PIP-USP2/CN
An IQ System
™
CobraNet
and DSP for Crown
© 2001 by Crown Audio, Inc., P.O. Box 1000, Elkhart, IN 46515-1000 U.S.A.
Telephone: 219-294-8000. Fax: 219-294-8329. PIP modules are produced by
Crown Audio, Inc. Trademark Notice: IQ2 ™ , SmartAmp ™ , PIP ™, and PIP2 ™ are
trademarks, and Com-Tech
registered trademarks of Crown International, Inc. Other trademarks are the
property of their respective owners.
Obtaining Other Language Versions:
To obtain information in another language about the use of this product, please
contact your local Crown Distributor. If you need assistance locating your local
distributor, please contact Crown at 219-294-8200.
Note: The information provided in this manual was
deemed accurate as of the publication date. How-
ever, updates to this information may have occurred.
To obtain the latest version of this manual, please
visit the Crown website at www.crownaudio.com.
®
Programmable Input Processor with
®
®
, Crown
®
, IOC
PIP2-Compatible Amplifiers
®
, IQ System
®
and ODEP
®
are
132404-1
4/01
