Key #
Part #
35
B050060109
36
1160010014
37
2030160119
38
4100050008
39
4010010106
40
3190060008
41
0212000011
42
4010010053
43
3160060043
44
3160060045
45
4030010002
46
1220040021
47
2010050037
48
3190060008
49
4010010060
50
3120040048
51
2040160143
52
2050030016
53
4090010010
54
2050060170
55
3120040047
56
3120010069
57
0212000011
58
2030070044
59
1230010118
60
2050050035
61
3150150024
62
2030050002
63
4030010099
64
6140020010
65
4030010006
66
2050050036
67
2030070045
68
1062020001
69
3140010072
70
20300500
71
6140020013
72
4020080016
73
2040160025
74
3120120113
75
3120120112
76
3120120111
77
2040160147
78
1180100007
79
4020020001
PARTS LIST
Part Name
Lock spring
Shaft lock
Bearing hold down
"E" ring dia. 7
Bearing 627-2RS
Sealing washer
Rotor
Bearing 607-2RS
Upper indicator light cover
Lower indicator light cover
Tapping screw ST2X4,5
Indicator light
Worm gear
Sealing washer
Bearing 608 2RS
Lock block
Pin, dia. 2X22
Spring
Hollow rivet, dia. 2.5X20
Spring
Lock button
Switch knob
Stator
Left brush holder
Carbon brush
Left brush spring
Brush holder support
Cord clamp
Tapping Screw ST3.9X10
Hex key, 3mm
Tapping screw ST2X6
Right brush spring
Right brush holder
Switch
Cord guard
Cord set
Hex key, 5mm
Hex screw M4X10
Knurled pin, dia. 2.2X12
Depth lock lever
Depth indicator
Depth slipping block
Pin
Guard screw
Screw M4X8
23
Quantity
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
2
1
4
1
1
1
1
1
1
1
1
1
1
1
1
1
4
