Click the Reset Statistics button to refresh this screen.
Field
Mode
Traffic Type
Status
Link Power State
Line Coding (Trellis)
SNR Margin (0.1 dB)
Attenuation (0.1 dB)
Output Power
(0.1 dBm)
Attainable Rate (Kbps)
Rate (Kbps)
In ADSL2+ mode, the following section is inserted.
MSGc
B
M
T
R
S
L
D
Delay
INP
In G.DMT mode, the following section is inserted.
K
R
S
D
Delay
OH Frames
OH Frame Errors
RS Words
RS Correctable Errors
RS Uncorrectable
Errors
Description
G.Dmt, G.lite, T1.413, ADSL2, ADSL2+,
Channel type Interleave or Fast
Lists the status of the DSL link
Link output power state.
Trellis On/Off
Signal to Noise Ratio (SNR) margin
Estimate of average loop attenuation in the downstream
direction.
Total upstream output power
The sync rate you would obtain.
Current sync rates downstream/upstream
Number of bytes in overhead channel message
Number of bytes in Mux Data Frame
Number of Mux Data Frames in FEC Data Frame
Mux Data Frames over sync bytes
Number of check bytes in FEC Data Frame
Ratio of FEC over PMD Data Frame length
Number of bits in PMD Data Frame
The interleaver depth
The delay in milliseconds (msec)
DMT symbol
Number of bytes in DMT frame
Number of check bytes in RS code word
RS code word size in DMT frame
The interleaver depth
The delay in milliseconds (msec)
Total number of OH frames
Number of OH frames received with errors
Total number of Reed-Solomon code errors
Total Number of RS with correctable errors
Total Number of RS words with uncorrectable errors
