6 - Setting up
No. Item
1 microSD card / SIM card
tray
2 3.5 mm headphone jack Connects to stereo headphones.
3 Second microphone
4 Power button
5 Phone speaker
6 Touchscreen
7 Front camera
8 Ambient light and
proximity sensors
9 Flash
10 Camera
11 Speaker
12 Volume up/down button
13 Micro USB connector
14 Microphone

Charging the battery

For initial use, you need to charge your smartphone for eight hours.
After that you can recharge the battery as needed.
Description
Accepts a microSD card and one or two SIM cards
(depends on model purchased).
Note: The microSD card replaces a SIM card in
models that support two SIMs.
Internal microphone for noise cancelation.
Press to turn the screen on/off or enter sleep
mode; press and hold to turn the smartphone on
or off.
Emits audio from your smartphone; suitable for
holding to your ear.
Touchscreen to display data, smartphone content
and enter information.
Front-facing camera suitable for video chats and
self-portraits.
Detect ambient light and proximity to control
screen brightness.
LED flash for taking photos in low-light
environments.
A camera for taking high-resolution images.
Built-in speaker for handsfree use or media
playback.
Increases or decreases the smartphone volume.
Connects to a USB cable/charger.
Internal microphone.
