Analog Initialize – the outputs of the Decade symbol must be connected to additional logic, not shown in the example below
Touchpanel
fb115 press115
fb116 press116
fb117 press117
fb118 press118
fb119 press119
fb120 press120
fb121 press121
fb122 press122
fb123 press123
fb124 press124
fb125 press125
Primer – DOC. 6253
Analog Initialize
Ch_preset_CBS
Ch_preset_NBC
Ch_preset_ABC
Ch_preset_PBS
Ch_preset_Comedy
Ch_preset_HBO
Ch_preset_HBO2
Ch_preset_HBOW
Ch_preset_ESPN
Ch_preset_On_Demand
Single-Input Form:
The second form of the Analog Initialize symbol is corollary to the first, in that now
there is only a single digital input, and multiple analog outputs. Aside from this
difference, the behavior of the symbol is essentially the same, except that on the
rising-edge of the digital input, each analog output is assigned the value specified by
its corresponding parameter.
This form of the Analog Initialize is useful if you have more than one analog signal
to assign values to. Of course in this case you will need one Analog Initialize symbol
for each set of values you wish to assign. If, for example, we wanted to modify the
example presented above so that instead of changing one TV's channel, we wanted to
change five TV's, each to a *different* channel (for, say, a sports bar), we could add
one Analog Initialize symbol with a single input and five analog outputs, and then
copy that symbol as many times as necessary (once for each desired preset),
changing the digital input and parameter values on each one, but leaving the five
analog outputs the same.
In addition, this form of the Analog Initialize is often used to initialize a number of
analog signals that never need to change as the program runs. This is useful when
2d
Preset_channel
4d
7d
13d
50d
82d
96d
301d
36d
500d
Software
Decade
ain units0
enable units1
units2
units3
units4
units5
units6
units7
units8
units9
tens0
tens1
tens2
tens3
tens4
tens5
tens6
tens7
tens8
tens9
hundreds0
hundreds1
hundreds2
hundreds3
hundreds4
hundreds5
hundreds6
hundreds7
hundreds8
hundreds9
